7.2.5.6. System Management > Power Up
Feature
Power Up
Power Up watchdog
Attention: F12 disables the
Power Up Watchdog.
ECO Mode
Power-up Mode
Attention: The Power-Up Mode
only has effect, if the module is
in ATX-Mode.
7.2.5.7. System Management > LVDS Backlight
Feature
LVDS Backlight
LVDS Backlight Bright
7.2.5.8. System Management > Smart Fan
Feature
Smart Fan
CPU Smart FanTemperature
Source
CPU Fan Mode
PWM Level
7.2.6. System Date and Time
Feature
System Date
System Time
BIOS Setup
Options
Info only
Enabled
Disabled
Disabled
Enable
Turn on
Remain off
Last State
Options
Info only
255
Options
Info only
CPU Sensor
System Sensor
AUTO (Smart Fan)
Fan Off
Fan On
100
Options
Weekday, MM/DD/YYYY
HH/MM/SS
Description
The Power-Up Watchdog resets the system after a
certain amount of time after power-up.
Reduces the power consumption of the system.
Turn On: The machine starts automatically when the
power supply is turned on.
Remain Off: To start the machine the power button
has to be pressed.
Last State: when powered on during a power failure
the system will automatically power on when power is
restored
Description
The value range starts by 0 and ends by 255.
Description
Select CPU smart fan source.
Select CPU Fan Mode.
Select PWM level.
Description
Requires the alpha-numeric entry of the day of the
week, day of the month, calendar month, and all 4
digits of the year, indicating the century and year (Fri
XX/XX/20XX)
Presented as a 24-hour clock setting in hours,
minutes, and seconds
