ADLINK Technology Express-KL2 User Manual page 48

Hex Range
52h – 53h
60h
61h
62h
63h
64h
65h
66h
67h
70h
71h
72h
73h
74h
75h
76h – 77h
80h
84h – 86h
88h
8Ch – 8Eh
90h
092
94h – 96h
98h
9Ch – 9Eh
A0h – A1h
A4h – A5h
A8h – A9h
ACh – ADh
B0h – B1h
B2h – B3h
B4h – B5h
B8h – B9h
BCh – BDh
200 – 207h
208–20Fh
4D0h – 4D1h
CF9h
42
Device
Timer/Counter
LPC/eSPI
NMI Controller
Microcontroller
NMI Controller1
Microcontroller
NMI Controller1
Microcontroller
NMI Controller1
RTC Controller
RTC Controller
RTC Controller
RTC Controller
RTC Controller
RTC Controller
RTC Controller
LPC/eSPI or PCIe
Reserved
Reserved
Reserved
(Alias to 80h)
Reset Generator
(Aliases to 8xh)
(Alias to 88h)
(Alias to 8xh)
Interrupt Controller
Interrupt Controller
Interrupt Controller
Interrupt Controller
Interrupt Controller
Interrupt Controller
Interrupt Controller
Interrupt Controller
Interrupt Controller
Gameport Low
Gameport High
Interrupt Controller
Reset Generator
System Resources
