ADLINK Technology Express-KL2 User Manual page 16

Row A
Pin Name
A36 USB6-
A37 USB6+
A38 USB_6_7_OC#
A39 USB4-
A40 USB4+
A41 GND (FIXED)
A42 USB2-
A43 USB2+
A44 USB_2_3_OC#
A45 USB0-
A46 USB0+
A47 VCC_RTC
EXCD0_PERST
A48 #
A49 EXCD0_CPPE#
A50 LPC_SERIRQ
A51 GND (FIXED)
A52 PCIE_TX5+
A53 PCIE_TX5-
A54 GPI0
A55 PCIE_TX4+
A56 PCIE_TX4-
A57 GND
A58 PCIE_TX3+
A59 PCIE_TX3-
A60 GND (FIXED)
A61 PCIE_TX2+
A62 PCIE_TX2-
A63 GPI1
A64 PCIE_TX1+
A65 PCIE_TX1-
A66 GND
A67 GPI2
A68 PCIE_TX0+
A69 PCIE_TX0-
A70 GND (FIXED)
A71 LVDS_A0+
A72 LVDS_A0-
A73 LVDS_A1+
A74 LVDS_A1-
A75 LVDS_A2+
A76 LVDS_A2-
A77 LVDS_VDD_EN
A78 LVDS_A3+
A79 LVDS_A3-
A80 GND (FIXED)
10
Row B
Pin Pin Name
B36 USB7-
B37 USB7+
B38 USB_4_5_OC#
B39 USB5-
B40 USB5+
B41 GND (FIXED)
B42 USB3-
B43 USB3+
B44 USB_0_1_OC#
B45 USB1-
B46 USB1+
B47 EXCD1_PERST#
B48 EXCD1_CPPE#
B49 SYS_RESET#
B50 CB_RESET#
B51 GND (FIXED)
B52 PCIE_RX5+
B53 PCIE_RX5-
B54 GPO1
B55 PCIE_RX4+
B56 PCIE_RX4-
B57 GPO2
B58 PCIE_RX3+
B59 PCIE_RX3-
B60 GND (FIXED)
B61 PCIE_RX2+
B62 PCIE_RX2-
B63 GPO3
B64 PCIE_RX1+
B65 PCIE_RX1-
B66 WAKE0#
B67 WAKE1#
B68 PCIE_RX0+
B69 PCIE_RX0-
B70 GND (FIXED)
B71 LVDS_B0+
B72 LVDS_B0-
B73 LVDS_B1+
B74 LVDS_B1-
B75 LVDS_B2+
B76 LVDS_B2-
B77 LVDS_B3+
B78 LVDS_B3-
B79 LVDS_BKLT_EN
B80 GND (FIXED)
Row C
Pin Pin Name
C36 PCI_DEVSEL#
C37 PCI_IRDY#
C38 PCI_C/BE2#
C39 PCI_AD17
C40 PCI_AD19
C41 GND (FIXED)
C42 PCI_AD21
C43 PCI_AD23
C44 PCI_C/BE3#
C45 PCI_AD25
C46 PCI_AD27
C47 PCI_AD29
C48 PCI_AD31
C49 PCI_IRQA#
C50 PCI_IRQB#
C51 GND (FIXED)
C52 PEG_RX0+
C53 PEG_RX0-
C54 TYPE0#
C55 PEG_RX1+
C56 PEG_RX1-
C57 TYPE1#
C58 PEG_RX2+
C59 PEG_RX2-
C60 GND (FIXED)
C61 PEG_RX3+
C62 PEG_RX3-
C63 RSVD
C64 RSVD
C65 PEG_RX4+
C66 PEG_RX4-
C67 RSVD
C68 PEG_RX5+
C69 PEG_RX5-
C70 GND (FIXED)
C71 PEG_RX6+
C72 PEG_RX6-
C73 SDVO_DATA
C74 PEG_RX7+
C75 PEG_RX7-
C76 GND
C77 RSVD
C78 PEG_RX8+
C79 PEG_RX8-
C80 GND (FIXED)
Pinouts and Signal Descriptions
Row D
Pin Pin Name
D36 PCI_FRAME#
D37 PCI_AD16
D38 PCI_AD18
D39 PCI_AD20
D40 PCI_AD22
D41 GND (FIXED)
D42 PCI_AD24
D43 PCI_AD26
D44 PCI_AD28
D45 PCI_AD30
D46 PCI_IRQC#
D47 PCI_IRQD#
D48 PCI_CLKRUN#
PCI_M66EN
D49 GND)
D50 PCI_CLK
D51 GND (FIXED)
D52 PEG_TX0+
D53 PEG_TX0-
PEG_LANE_RV
D54 #
D55 PEG_TX1+
D56 PEG_TX1-
D57 TYPE2#
D58 PEG_TX2+
D59 PEG_TX2-
D60 GND (FIXED)
D61 PEG_TX3+
D62 PEG_TX3-
D63 RSVD
D64 RSVD
D65 PEG_TX4+
D66 PEG_TX4-
D67 GND
D68 PEG_TX5+
D69 PEG_TX5-
D70 GND (FIXED)
D71 PEG_TX6+
D72 PEG_TX6-
D73 SDVO_CLK
D74 PEG_TX7+
D75 PEG_TX7-
D76 GND
D77 IDE_CBLID#
D78 PEG_TX8+
D79 PEG_TX8-
D80 GND (FIXED)
