ADLINK Technology Express-KL2 User Manual page 73

7.3.11.1. Serial Port Console > Console Redirection Settings
Feature
Console Redirection Settings
Terminal Type
Bits per second
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection
Putty KeyPad
Redirection After BIOS Post
7.3.12. ICC Configuration
Feature
ICC Information
Note: The item is "info only" in the standard BIOS. The options can be opened by customer request.
BIOS Setup
Options Description
Info only
VT100 Emulation: ANSI: Extended ASCII char set. VT100:
ASCII char set. VT100+: Extends VT100 to support
VT100+
color, function keys, etc. VT-UTF8: Uses UTF8
VT-UTF8
encoding to map Unicode chars onto 1 or more bytes.
ANSI
9600 Selects serial port transmission speed.
19200
38400
57600
115200
7 Select Data Bits.
8
Select Parity.
None
Even
Odd
Mark
Space
1 Select number of stop bits.
2
Select flow control.
None
Hardware RTS/CTS
Disabled Enable VT-UTF8 Combination Key Support for
ANSI/VT100 terminals.
Enable
With this mode enabled only text will be sent. This is
Disabled
to capture Terminal data.
Enable
Enables or disables extended terminal resolution
Disabled
Enable
On Legacy OS, the Number of Rows and Columns
80x24
supported redirection
80x25
Select FunctionKey and KeyPad on Putty.
VT100
LINUX
XTERMR6
SCO
ESCN
VT400
The Settings specify if BootLoader is selected than
Always Enabled
Legacy console redirection is disabled before booting
BootLoader
to Legacy OS. Default value is Always Enable which
means Legaacy console Redirection is enabled for
Legacy OS.
Options Description
Info only
Express-KL2
67
