3.3.6. PCI Express
Signal Pin #
PCIE_TX0+ A68
PCIE_TX0- A69
PCIE_RX0+ B68
PCIE_RX0- B69
PCIE_TX1+ A64
PCIE_TX1- A65
PCIE_RX1+ B64
PCIE_RX1- B65
PCIE_TX2+ A61
PCIE_TX2- A62
PCIE_RX2+ B61
PCIE_RX2- B62
PCIE_TX3+ A58
PCIE_TX3- A59
PCIE_RX3+ B58
PCIE_RX3- B59
PCIE_TX4+ A55
PCIE_TX4- A56
PCIE_RX4+ B55
PCIE_RX4- B56
PCIE_TX5+ A52
PCIE_TX5- A53
PCIE_RX5+ B52
PCIE_RX5- B53
PCIE_CLK_REF+ A88
PCIE_CLK_REF- A89
3.3.7. Express Card
Signal Pin # Description
EXCD0_CPPE# A49
EXCD1_CPPE# B48
EXCD0_PERST# A48
EXCD1_PERST# B47
16
Description
PCI Express channel 0, Transmit
Output differential pair.
PCI Express channel 0, Receive Input
differential pair.
PCI Express channel 1, Transmit
Output differential pair.
PCI Express channel 1, Receive Input
differential pair.
PCI Express channel 2, Transmit
Output differential pair.
PCI Express channel 2, Receive Input
differential pair.
PCI Express channel 3, Transmit
Output differential pair.
PCI Express channel 3, Receive Input
differential pair.
PCI Express channel 4, Transmit
Output differential pair.
PCI Express channel 4, Receive Input
differential pair.
PCI Express channel 5, Transmit
Output differential pair.
PCI Express channel 5, Receive Input
differential pair.
PCI Express Reference Clock output
for all PCI Express and PCI Express
Graphics Lanes.
PCI ExpressCard: PCI Express capable
card request
PCI ExpressCard: reset
I/O PU/PD
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I/O PU/PD Comment
I 3.3V PU 10k
3.3V
O 3.3V
Pinouts and Signal Descriptions
Comment
AC coupled on Module
AC coupled off Module
AC coupled on Module
AC coupled off Module
AC coupled on Module
AC coupled off Module
AC coupled on Module
AC coupled off Module
AC coupled on Module
AC coupled off Module
AC coupled on Module
AC coupled off Module
