Feature
Hsync Polarity
LVDS/eDP Backlight Mode
GTT LVDS/eDP Backlight Control
PEG/DDI MUX Select
DDI port 1
DDI port 2
Primary IGFX Boot Display
Select Secondary Display
LCD Panel Type
Active LFP
Panel Scaling
RC6(Render Standby)
56
Options Description
Hsync Polarity select
Active High
Active Low
Select LVDS Backlight control function.
BMC Mode
GTT Mode
0% Actual backlight value in percent of the maximum
setting.
20%
40%
60%
80%
100%
PEG/DDI select
PEG
DDI
No device DDI port 1 function choose to Display Port or HDMI.
Display Port
HDMI
DisplayPort with
HDMI/DVI Compatible
No device DDI port 2 function choose to Display Port or HDMI.
Display Port
HDMI
DisplayPort with
HDMI/DVI Compatible
Select the Video Device which will be activated during
VBIOS Default
POS.
Select Secondary Display Device.
Disabled
Select LCD panel used by Internal Graphics Device by
VBIOS Default
selecting the appropriate setup item.
640X480
800X600
1024X768
1280X1024
1400X1050
1600X1200
1366X768
1680X1050
1920X1200
1440X900
1600X900
1024X768 LVDS2
1280X800
1920X1080
2048X1536
No LVDS Select the Active LFP Configuration.
eDP Port-A
Select the LCD panel scaling option used by the
Auto
Internal Graphics Device.
Off
Force Scaling
Enable Check to enable render standby support.
Disable
