Row A
Pin Name
A81 LVDS_A_CK+
A82 LVDS_A_CK-
A83 LVDS_I2C_CK
A84 LVDS_I2C_DAT
A85 GPI3
A86 KBD_RST#
A87 KBD_A20GATE
PCIE0_CK_REF
A88 +
PCIE0_CK_REF
A89 -
A90 GND (FIXED)
A91 SPI_POWER
A92 SPI_MISO
A93 GPO0
A94 SPI_CLK
A95 SPI_MOSI
A96 GND
A97 TYPE10#
A98 RSVD
A99 RSVD
A100 GND (FIXED)
A101 RSVD
A102 RSVD
A103 RSVD
A104 VCC_12V
A105 VCC_12V
A106 VCC_12V
A107 VCC_12V
A108 VCC_12V
A109 VCC_12V
A110 GND (FIXED)
Note: SATA port 3 is supported by build option, in place of PATA port.
Pinouts and Signal Descriptions
Row B
Pin Pin Name
B81 LVDS_B_CK+
B82 LVDS_B_CK-
LVDS_BKLT_CT
B83 RL
B84 VCC_5V_SBY
B85 VCC_5V_SBY
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
B89 VGA_RED
B90 GND (FIXED)
B91 VGA_GRN
B92 VGA_BLU
B93 VGA_HSYNC
B94 VGA_VSYNC
B95 VGA_I2C_CK
B96 VGA_I2C_DAT
B97 SPI_CS#
B98 RSVD
B99 RSVD
B100 GND (FIXED)
B101 RSVD
B102 RSVD
B103 RSVD
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND (FIXED)
Row C
Pin Pin Name
C81 PEG_RX9+
C82 PEG_RX9-
C83 RSVD
C84 GND
C85 PEG_RX10+
C86 PEG_RX10-
C87 GND
C88 PEG_RX11+
C89 PEG_RX11-
C90 GND (FIXED)
C91 PEG_RX12+
C92 PEG_RX12-
C93 GND
C94 PEG_RX13+
C95 PEG_RX13-
C96 GND
C97 RSVD
C98 PEG_RX14+
C99 PEG_RX14-
C100 GND (FIXED)
C101 PEG_RX15+
C102 PEG_RX15-
C103 GND
C104 VCC_12V
C105 VCC_12V
C106 VCC_12V
C107 VCC_12V
C108 VCC_12V
C109 VCC_12V
C110 GND (FIXED)
Express-KL2
Row D
Pin Pin Name
D81 PEG_TX9+
D82 PEG_TX9-
D83 RSVD
D84 GND
D85 PEG_TX10+
D86 PEG_TX10-
D87 GND
D88 PEG_TX11+
D89 PEG_TX11-
D90 GND (FIXED)
D91 PEG_TX12+
D92 PEG_TX12-
D93 GND
D94 PEG_TX13+
D95 PEG_TX13-
D96 GND
D97 PEG_ENABLE#
D98 PEG_TX14+
D99 PEG_TX14-
D100 GND (FIXED)
D101 PEG_TX15+
D102 PEG_TX15-
D103 GND
D104 VCC_12V
D105 VCC_12V
D106 VCC_12V
D107 VCC_12V
D108 VCC_12V
D109 VCC_12V
D110 GND (FIXED)
