2.16. Functional Diagram

SODIMM 1
2133/2400 MHz
DDR4
SODIMM 2
2133/2400 MHz
DDR4
single/dual
eDP - LVDS
18/24 bit LVDS
VGA
DP-to-VGA
6x PCIe x1 Gen3
(port 0-5)
GbE
i219 LM/V
3x SATA 6Gb/s
(port 0/1/2)
1x SATA 6Gb/s (port 3)
8x USB 2.0
HD Audio
SMBus
GPIO
4GPI, 4GPO
GP I2C
DDC I2C
Specifications
Intel® Celeron®
eDP x4
eDP x2
PCIe x1
QM175/HM175/CM238
TPM
2.0
LPC bus
SPI_CS#
SPI

Figure 1: Express-KL2 Functional Block Diagram

th
Mobile 7 Gen
Intel® Xeon®
Intel® Core™
Processor
("Kaby Lake H")
Mobile Intel®
Chipset
SMBus
New
SEMA
BMC
Switch
PEG or
DDI
PCIe-to-PCI
SATA
SATA-to-PATA
SPI 0
BIOS
SPI 1
BIOS
Thermal
Sensor
Express-KL2
PEG
or
DDI 1
DDI 2
7
