9.4 Parameter list

Control Panel Display and Keys are Not present for Option Codes: 2/3/4/D (see table pag. 15)
This chapter describes the parameter on the menus accessed via the control panel and Configurator software.
To learn how to access the menus described below see "Menu navigation" chapter.
Menu Listing
The table below lists the parameters found on each menu. See the following pages for descriptions and other
details of each parameter.
Operator Setup
Set Point Out Scale
Volts Out I Limit SP
Current Nom Line V
Power Nominal I
Volts In Soft Start
Frequency SP Select
Pwr Factor
Load Ω
I Limit SP
Out Scale
Nom Line V
Nominal I
Read/write Read only
Advanced Setup
Firing Type
Min Cycle Analog in 2
Soft Start
Start Ramp
Delay
Cycle Time
Feedback
Pb Power
Ti Power
Pb Current
Ti Current
HB Sense
HB Delay
Htr Bake
28
Hardware Communication
Analog in 1 Port 1 Baud
Port 1 Addr
An2 Funct Port 2 Baud
DI1 Functn Watchdog
DI2 Functn WD Reset
Alm Out Fn Port 2
IL SP Src
Start Disp
User's manual
Monitoring
Dig in 1
Dig in 2
Enable
SP Source
Analog In1
Analog In2
SW Ver
SW Rel
Unit Type
Max Voltage
Max Current
Aux Voltage
Serial No.
