9.4 Parameter list

This chapter describes the parameter on the menus accessed via the control panel and Configurator software.
To learn how to access the menus described below see "Menu navigation" chapter.
9.4.1 Operator Menu
This section describes each item on the operator menu. Use this menu to view the measured values and basic
settings of the power controller. The password to access this menu is 0.
Parameter Name
SET POINT View the set point
Indicates the average (RMS) voltage of all
V Output
phases
Indicates the average (RMS) current of all
I Output
phases
Power Indicates the average (RMS) power output
V Input Indicates the average (RMS) voltage input
Frequency Indicates frequency of the power input
Power Factor Indicates power factor of the output power
Load Ω Indicates the resistance of the load
Indicates the percentage by which the power
Out Scale
demand set point is scaled
Indicates the user-set, nominal value for the
Nominal V
line voltage input
Nominal I Indicates the user-set, nominal load current
Description
32
User's manual
Modbus
Range Unit
Address
0 to 100 %
0 to 1023 V
0 to 1023 V
0 to 100 %
0 to 65535 V
0 to 655.35 Hz
0 to 1000
0 to 655.35 Ω
0 to 100.0 %
0 to 1023 V
0 to 999.9 A
Par.
Type
Read
15
Only
Read
10
Only
Read
11
Only
Read
12
Only
Read
47
Only
Read
9
Only
Read
102
Only
Read
46
Only
Read
16
Only
Read
37
Only
Read
38
Only
