CANopen RUN LED (green)
®
The CANopen RUN LED indiates the status of the CANopen
CAN RUN LED State
Flickering AutoBaud/LSS
Single flash STOPPED
Blinking PRE-OPERATIONAL The device is in the PRE-OPERATIONAL state.
On OPERATIONAL
Whilst the device is executing a reset the CANopen
In case there is a conflict between turning the LED on green versus red, the LED may be turned
on red. Apart from this situation, the bicolor status LED shall combine the behavior of the CAN
Error LED.
8.3.3

LED "Power"

This LED is connected directly to the (optionally also electrically isolated) supply voltage of the
serial interface (RS232/422/485).
8.3.4

LED "State"

Lights green
Flashes green
Flashes green/red
Lights red
Flashes red
8.3.5

LEDs 1 / 2 / 4 / 8 (Error No / Select ID)

If these 4 LEDs flash and LED "State" simultaneously lights red, the error number is displayed in
binary notation (conversion table, see Annex) in accordance with the table in chapter "Error han-
dling". Additionally there LEDs are controllable via Script.
8.4

Switches

The Gateway features 4 switches with the following functions:
Rotary coding switch S4
Rotary coding switch S5
Termination (CANopen
DIP-switch
8.4.1

Rotary coding switches S4 + S5 (serial interface)

This value is read in when the gateway is switched on.
25.9.20 Fieldbus-Gateway UNIGATE
Description
Auto Baudrate detection in progress or LSS services in progress
(alternately flickering with RUN LED).
The device is in STOPPED state.
The device is in the OPERATIONAL state.
Data exchange active
Connection ok but no constant data exchange
No data exchange since switching on
general gateway error (see LED's Error No.)
UNIGATE is in configuration / test mode
ID High for serial interface i. e. configmode
ID Low for serial interface i. e. configmode
®
) switchable CANopen
Node-ID and baud rate
®
Hardware ports, switches and LEDs CANopen (Mapping)
®
network state machine
®
RUN LED shall be off.
®
-terminating resistor
CX C4Map - DeviceNet V. 1.0
.
