Deutschmann Automation GmbH & Co. KG
7.4
The length byte
The user can configure whether the transmit length is also to be stored as a byte in the input/out-
put data area (Fieldbus lengthbyte
this byte are sent. On reception of a telegram the gateway enters the number of characters
received.
7.5
Swap word
When "Swap word" is activated, the data is exchanged word by word to and from the fieldbus.
I.e. High and low bytes in a 16 bit word are exchanged and transferred to the CAN bus.
It affects the entire fieldbus buffer.
25.9.20
Fieldbus-Gateway UNIGATE
Implemented protocols in UNIGATE® CX C4Map
→
active). In transmit direction, as many bytes as specified in
®
CX C4Map - DeviceNet V. 1.0
23
