Hardware ports, switches and LEDs CANopen (Mapping)
8.3.2

LED "(Bus) State"

Indicator states and flash rates
The following Indicator states are distinguished:
LED on constantly on
LED off constantly off
LED flickering iso-phase on and off with a frequency of approximately 10 Hz: on for approxi-
mately 50 ms and off for approximately 50 ms.
LED blinking iso-phase on and off with a frequency of approximately 2,5 Hz: on for approxi-
mately 200 ms followed by off for approximately 200 ms.
LED single flash one short flash (approximately 200ms) followed by a long off phase (approxi-
mately 1000 ms).
LED double flash a sequence of two short flashes (approximately 200ms), separated by an off
phase (approximately 200ms). The sequence is finished by a long off phase
(approximately 1000 ms).
LED triple flash a sequence of three short flashes (approximately 200ms), separated by an off
phase (approximately 200ms). The sequence is finished by a long off phase
(approximately 1000 ms).
If one bicolor Status LED is used instead of two single color LEDs, this LED shall indicate both
the physical bus status and the status of the CANopen
red and green.
®
CANopen ERROR LED (red)
®
The CANopen Error LED indicates the status of the CAN physical layer and indicates errors due
to missing CAN messages (SYNC, GUARD or HEARTBEAT).
ERROR LED State
Off No error
Single flash Warning limit reached At least one of the error counters of the CAN controller has
Flickering AutoBaud/LSS
Double flash Error Control Event
Triple flash Sync Error
On Bus Off
If at a given time several errors are present, the error with the highest number is indicated (e.g. if
NMT Error and Sync Error occur, the SYNC error is indicated).
26
Description
The Device is in working condition.
reached or exceeded the warning level (too many error frames).
Auto Baudrate detection in progress or LSS services in
progress (alternately flickering with RUN LED).
A guard event (NMT-Slave or NMT-master) or a heartbeat event
(Heartbeat consumer) has occurred.
The SYNC message has not been received within the configured
communication cycle period time out (see Object Dictionary Entry
0x1006).
The CAN controller is'bus off
Fieldbus-Gateway UNIGATE
Deutschmann Automation GmbH & Co. KG
®
state machine. This bicolor LED shall be
®
