Deutschmann Automation GmbH & Co. KG
Blinking PRE-OPERATIONAL
On OPERATIONAL
Whilst the device is executing a reset the CANopen
In case there is a conflict between turning the LED on green versus red, the LED may be turned
on red. Apart from this situation, the bicolor status LED shall combine the behavior of the CAN
Error LED.
8.3.3

LED "Power"

This LED is connected directly to the (optionally also electrically isolated) supply voltage of the
serial interface (RS232/422/485).
8.3.4

LED "State"

Lights green
Flashes green
Flashes green/red
Lights red
Flashes red
8.3.5

LEDs 1 / 2 / 4 / 8 (Error No / Select ID)

If these 4 LEDs flash and LED "State" simultaneously lights red, the error number is displayed in
binary notation (conversion table, see Annex) in accordance with the table in chapter "Error han-
dling". Additionally there LEDs are controllable via Script.
8.4

Switches

The Gateway features 4 switches with the following functions:
Rotary coding switch S4
Rotary coding switch S5
Termination (CANopen

DIP-switch

8.4.1

Rotary coding switches S4 + S5 (serial interface)

This value is read in when the gateway is switched on.
8.4.2 Termination (CANopen
If the Gateway is operated as the first or last physical device in the CANopen
bus termination at this Gateway. In order to do this, either a bus terminating resistor must be acti-
vated in the connector or the resistor (220 ) integrated in the Gateway must be activated. In
order to do this, slide the slide switch to position ON. In all other cases, the slide switch must
remain in position OFF. Please refer to the general Fieldbus literature for further information on
the subject of bus termination.
Note: To activate or deactivate the bus termination, please remove the BUS-connector and care-
fully set the switch to the desired position.
8.4.3 DIP-Switch
The DIP-switch is used to set the Node-ID and Baud rate according to picture 3.
28.9.20 Fieldbus-Gateway UNIGATE
The device is in the PRE-OPERATIONAL state.
The device is in the OPERATIONAL state.
Data exchange active
Connection ok but no constant data exchange
No data exchange since switching on
general gateway error (see LED's Error No.)
UNIGATE is in configuration / test mode
ID High for serial interface i. e. configmode
ID Low for serial interface i. e. configmode
®
) switchable CANopen
Node-ID and baud rate
® )
®
Hardware ports, switches and LEDs CANopen (Mapping)
®
RUN LED shall be off.
®
-terminating resistor
CX C4Map - PROFIBUS V. 1.0
®
, there must be a
27
