6. Switch Configuration

This chapter explains how to set up the STS16-20RM or the STS16-20FRM Token
Ring switch and how to modify the configuration using a VT100 console attached
to the switch directly or via a modem connection. The switch configuration can also
be modified from a remote VT100 console via a telnet session.
For information on how to connect the console, see Chapter 5, "Accessing Switch
Management".
Subjects covered in this chapter:
•
General guidelines (page 72)
•
Main menu screen (page 74)
•
Configuration menu (page 75)
•
Switch and stack configuration (page 76)
•
Module information (page 80)
•
Virtual LANs (page 82)
•
IP Configuration (page 91)
•
Spanning tree protocol (STP) (page 94)
•
Port configuration (page 104)
•
CrossLink channels (page 109)
•
Address filtering (page 115)
•
Address aging (page 125)
•
Console password (page 129)
•
Console/telnet sessions (page 131)
•
Syslog facility (page 138)
•
DSRR configuration (page 140)
•
Download/Upload menu (page 146)
•
Reset menu (page 151)
Switch Configuration SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01
71
