89
MTU
Maximum Transfer Unit of the BRF (maximum size of the information field in
transmitted packets). Possible values are 1,500, 4,472 (default), 8,144, and 17,800.
The actual value used also depends on the hardware and the value configured for
the port (the smaller value is used).
These values correspond to maximum frame size values of 1,548, 4,546 (default),
9,236, and 18,192 respectively.
Bridge Number
Source routing bridge number for this BRF. Possible hexadecimal values are 0
through F. The default is F.
802.1Q VLAN ID
This parameter configures the QTAG to be used for High-Speed Token-Ring and
Translational Switching. If Q-tagging is used for this BRF, the default is set to the
VLAN ID of the BRF. Refer to the guide shipped with the relevant module.
LAA VLAN MAC Address
Used to configure a LAA MAC address used for in-band management of the
switch.
Note! The switch must be rebooted before this configuration takes effect.
Switch Configuration SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01
