Message Log Information Screen - Cabletron Systems SmartSTACK STS16-20RM Installation And User Manual

Message Log Information Screen

To open this screen from the main menu, select Statistics
Information.
The data on this screen is useful to technical experts in solving complex problems.
The message log will be preserved through resets, but will be cleared after a
configuration download. The messages in the log can also be send to a syslog
receiver see page 138 in Chapter 6, "Switch Configuration".
Whenever there are unread messages in the Message log a "*" will be shown in the
upper right corner of the console.
Log
Index number identifying the log file.
Type
Message type. Possible values are:
•
W—Warning
•
I—Informational
Message Content
The full text of the message.
More
Shows the next screen.
Monitoring the Network from the Console Statistics Menu SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01
195
Message Log
