Display Summary Screen

To open this screen from the main menu, select Statistics
This screen gives access to the most important switch configuration parameters in
a summary form. The information is suitable for saving to an ASCII file by means
of a capture function in the terminal emulation program used. This file will often
be requested by the Cabletron technical support in case of troubleshooting:
SPACE
Pressing the
which runs through the display, until you stop it, or the bottom is reached. Press any
key to return to the menu.
ESC
Pressing
ESC
Monitoring the Network from the Console Statistics Menu
key, you will start a screen report of all entered parameters,
SPACE
, you cancel and return to previous menu.
SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01
197
Display Summary.
