5. If you still can not get the connection to work, contact technical support as
described in Chapter 11, "Getting in Touch with Technical Support".

Diagnostic Screen

The diagnostic self-test displays two different screens, depending on whether you
perform a cold boot (power-on cycle with full diagnostics), or a warm boot (a reset
without full diagnostics). The warm boot contains portions of the complete cold
boot list.
The following is an example of a diagnostic screen during a boot process. The
actual screen may vary depending on, for example, hardware, options, and software
version levels:
BootStrap Firmware v2.3, Copyright 1996-1998
- Initiating bootstrapping sequence.
- Boot image integrity check...Passed.
- Control transferred to boot process.
Boot Firmware (Phase II) v2.3
- Program memory test........Passed.
- Relocating main image to
DRAM.......................................Done.
- Main image integrity check...succeeded.
- Control transferred to main process.
- Starting Power On Self Test Diagnostics.
- Network memory test 32-bits........Passed.
- Network memory test 16-bits........Passed.
- Network memory test 8-bits........Passed.
- Port register and memory test.....................Passed.
- Single port loopback test.....................Passed.
- All ports linked loopback test.....................Passed.
- Port MAC test.....Passed.
- Completed Power On Self Test Diagnostics.
System Software Version 4.0.0, Copyright 1994-1999.
System started on Mon. June 21, 1999 14:30:03
8 Megabytes System memory
2 Megabytes Network memory
- Initialization started
- File system initialized
- System temperature is within safe operating levels
- Checking file system integrity
- Warmboot initialization started
- LAN ports detected:
- RJ-45 Token Ring: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
- StkPort
Accessing Switch Management
: 29
SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01
69
