8. Monitoring the Network with SNMP

This chapter explains how to monitor the STS16-20RM and the STS16-20FRM
Token Ring switch from a network management system using an application that
supports Simple Network Management Protocol (SNMP).
The following topics are described in this chapter:
•

SNMP setup

•
IP configuration
•
SNMP configuration
SNMP Setup
Follow these steps to use in-band management:
1. Attach the switch to the console and start a console session as described in
Chapter 5, "Accessing Switch Management".
2. Make the necessary configurations in the IP Configuration screen.
3. Make the necessary configurations in the SNMP Configuration menu and the
following subscreens:
•
Community String screen
•
Trap Receiver screen
The following sections describe the SNMP setup screens.

IP Configuration Screen

The IP Configuration screen sets the IP address, gateway address, subnet mask,
and IP state.
The IP Address and Default Gateway must be in the same subnet address class—
that is, Class A, Class B, or Class C. The system prevents you from entering values
from different classes. If you do inadvertently enter an incorrect value, enter 0.0.0.0
in every field, then reenter the correct values.
Refer to Chapter 6, "Switch Configuration" for a complete description on how to
configure the IP Configuration menu.
Monitoring the Network with SNMP SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01
199
