118
— Any packet with the specified destination address is prevented from
entering the switch through the specified port(s).
•
Allow any packet with source address—Allow Src
— If a packet is received with a specified source address, it is allowed to enter
through the specified port(s). This feature is used in conjunction with port
security.
•
Allow any packet with destination address—Allow Dest
— If a packet is sent to a specified address, it is allowed to enter the switch
through the specified port(s). This feature is used in conjunction with port
security.
•
Force a packet with the destination address to certain port—Force Dest
— Packets with a specified address must go to the specified port.
Note: Force a packet is for test in network or troubleshooting only. Must not be
combined with Port Security Filter.
Applied Ports
The input port(s) that this filter entry is applied to (for that specified MAC address).
Exit Ports
The specified port(s) where a packet is allowed to go, or forced to go (for that
specific MAC address). This applies only to the Allow lma and Force Dest filters.
SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01 Switch Configuration
