1. Introduction

This chapter discusses switching technology and how the SmartStack STS16-
20RM and/or the STS16-20FRM Token Ring Switch can be used to improve
network performance. This chapter also includes a list of features and
specifications for the switch.
Note: References to SmartStack STS16-20RM are also applicable to SmartStack
STS16-20FRM.
The topics of this chapter are presented under the following titles:
•
"Switching Technology", starting on page 2.
•
"Front Panel Details" starting on page 5 and "Back Panel Details" starting on
page 10.
•
"Back Panel Details", starting on page 10.
The folloiwing figures display a front view of the STS16-20RM and the STS16-
20FRM Token Ring switches.

Figure 1. SmartStack STS16-20RM Token Ring Switch

Figure 2. SmartStack STS16-20FRM Token Ring Switch
