RMON Support

RMON is an industry-standard method for providing network statistics monitoring
using SNMP. It also collects fault, performance, and configuration statistics. It can
monitor continuously, even when communication with the management station is
not possible or efficient. RMON can then notify the management station when an
exceptional condition occurs.
In typical SNMP management, the SNMP client has to continuously poll the switch
for fault, performance, and configuration information, waiting for the value to
change. This causes increased traffic through the network. With RMON, you can
have the switch monitor a particular statistic internally, and when the statistics
reaches a threshold, the switch will send a trap to the client. This monitoring
method reduces traffic between the SNMP client and the switch.
The switch implements a mini RMON probe for the physical ports by supporting
some of the RMON groups RFC 1757 and RFC 1513.
For full RMON an external probe must be used.
For information on supported groups, see the following table:
Name
1. Statistics:
2. History
3. Alarm
4. Hosts
5. HostTopN
6. Matrix
7. Filter

Table 9. Supported RMON Groups

SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01
Support Info
Supported:
— The Token-Ring MAC-Layer Statistics Group.
The Token-Ring Promiscuous Statistics Group.
— The Ethernet Statistics Group.
Supported:
— The Token-Ring MAC-Layer History Group.
— The Token-Ring Promiscuous History Group.
— The Ethernet History Group.
— Supported for all RMON variables.
— Not supported for other MIB variables.
Not supported.
Not supported.
Not supported.
Not supported.
