Appendix B. Cable and Pin Information

This appendix provides information on cables that can be used with the STS16-
20RM and the STS16-20FRM Token Ring switches. It also provides minimum pin-
out information to be used to verify that the cables are correctly wired.

Connecting to the Out-of-Band Management Port

Table 13 lists the type of cables that are used when connecting to the OBM port
(labeled MANAGEMENT) on the front panel of the switch.
Cable Function
Connect a modem to the
MANAGEMENT port.
Connect a PC or other DTE
device to the
MANAGEMENT port.

Table 13. Connecting to the Management Port

Cable and Pin Information
Cable Type or Cable Solution
Connect one end of a straight-through
TIA/EIA-232 modem cable to the
MANAGEMENT port and the other end to
the modem.
Connect one end of a crossover TIA/EIA-
232 cable to the MANAGEMENT port and
the other end to the PC or DTE device
or
attach a null-modem adapter to the
MANAGEMENT port. Then, attach a
straight-through modem cable to the null-
modem adapter.
