Back Panel Details
The back panel of the switches are illustrated in Figure 5.
Figure 5. The Back Panel
Table 4 lists the back panel connectors on the switch.
Name
AC connection
Redundant power
supply
Table 4. Back Panel Switches and Connectors
SmartStack STS16-20RM/STS16-20FRM Token Ring Switches, P/N: 9032957-01
Standard AC power connection.
Connector for the optional redundant power supply unit.
Description
