d. parity value
e. flow control type
f. mode:
• Autosense (default): can be either terminal or PPP-async. Requires user interaction
(four carriage returns) to get to terminal mode.
• Term: terminal mode only. Login prompt automatically sent to remote console.
C L
ONFIGURING A INE FOR A
1. Enter the line name.
2. Select the line's slot and port combination.
3. Select following line characteristics:
• framing type
• line coding type
• T1 signaling method
If you are unsure of your line's characteristics, try the following defaults:
Characteristic
Framing type
Line coding type
Signaling Method
4. Select the correct T1 line build out value (US only). If you are using an external CSU, specify a
short haul build out (line length in meters). If you do not have an external CSU, specify a long
haul build out (decibel attenuation value from Telco).
5. A data link is assigned to the line upon completion of the line configuration. Add more data
links or modify the existing data link.
a. Only if you plan on using X.25 over the D-Channel on this line, answer yes to the following
prompt:
Will this Data Link support X.25 communications (Y/N)? [default N]
b. Assign a TEI Negotiation value of 0.
Note: You must delete the data link for a Robbed Bit line.
U M M C
SING ANAGE ODE OMMANDS
line
Displays the current line configuration.
datalink
Display the current data link configuration.
PRI R
ESOURCE
PRI/T1 lines
B8ZS
Common_Channel
C
ONFIGURING
ESF Multiframe CRC
Workgroup Remote Access Switch
R
ESOURCES AND
E1 line
N/A
N/A
L
INES
Lines
