- Page 1 Small Office Small Office R E M O T E A C C E S S S W I T C H MALL FFICE EMOTE CCESS WITCH UICK TART Release 7.2 Cabletron Systems (603) 332-9400 phone (603) 337-3075 fax support@ctron.com...
- Page 2 QUICK START Only qualified personnel should perform installation procedures. CAUTION NOTICE You may post this document on a network server for public use as long as no modifications are made to the document. Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice.
-
Page 3: Fcc Notice
TRADEMARKS Cabletron Systems, CyberSWITCH, MMAC-Plus, SmartSWITCH, SPECTRUM, and SecureFast Virtual Remote Access Manager are trademarks of Cabletron Systems, Inc. All other product names mentioned in this manual are trademarks or registered trademarks of their respective companies. COPYRIGHTS All of the code for this product is copyrighted by Cabletron Systems, Inc. ©... - Page 4 QUICK START WARNING: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. DOC NOTICE This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
-
Page 5: Table Of Contents
CONTENTS Using Quick Start Cabling The PC to CyberSWITCH Connection Using a10BaseT Hub LAN Connection Using a10BaseT Direct LAN Connection Using a 10Base2 (BNC) LAN Connection Using an AMP Connection For Out-of-Band Management For LAN Replacement For Local Console Access Using an AMP Connection for LAN Replacement or Local Console Access The ISDN Connection CyberSWITCHs with Internal NT-1s... - Page 6 Connecting One Cabletron Product to another via PPP Bridge to Bridge Configuration Configuration for Site "Central" Configuration for Site "Remote" IP Router to IP Router Configuration Configuration for Site "Central" Configuration for Site "Remote" IPX Router to IPX Router Configuration Configuration for Site "Central"...
-
Page 7: Using Quick Start
SING UICK TART This guide is for the CSX154 and the CSX155; collectively known as the CSX150 Series. To simplify the documentation, throughout this guide we will refer to these products as CSX150. Follow the instructions in this guide for installing the CyberSWITCH, powering it up, and making any necessary changes to the default configuration values. -
Page 8: Cabling
ABLING CyberSWITCH cabling includes the following: • connecting your PC to the CyberSWITCH • providing an ISDN connection for the CyberSWITCH • optional: connecting telephone devices to the CyberSWITCH using a POTS connection • connecting the CyberSWITCH to the provided power supply This chapter describes each of the cabling processes. -
Page 9: Using A10Baset Hub Lan Connection
LAN C SING A If you plan on using a 10BaseT Hub to connect one or more PCs to the CyberSWITCH, this is the type of connection you will use. Use the following graphic and instructions to complete the connection. Connect your PC to the Hub using the supplied straight through cable (RJ-45 connectors with twisted pair). -
Page 10: Using A10Baset Direct Lan Connection
QUICK START LAN C SING A IRECT If you plan on connecting your PC directly to an CyberSWITCH, this is the type of connection you will use. Use the following graphic and instructions to complete the connection. Connect your PC to the CyberSWITCH using a crossover cable. This cable is a custom made cable using RJ-45 connectors and twisted pair. - Page 11 If you wish to make your own, the pinouts for the crossover cable’s connectors are color-coded as follows: Ethernet 10Base-T Crossover Patch Cord wht/ora ora/wht wht/blu blu/wht 12345678 wht/grn grn/wht wht/brn brn/wht The PC to CyberSWITCH Connection ABLING 12345678 CyberSWITCH...
-
Page 12: Using A 10Base2 (Bnc) Lan Connection
QUICK START 2 (BNC) LAN C SING A If you plan on connecting your PC to an CyberSWITCH using the 10Base2 LAN port, this is the type of connection you will use. Note that the 10Base2 LAN port is an optional CyberSWITCH feature. Use the following graphic and instructions to complete the connection. -
Page 13: Using An Amp Connection
AMP C SING AN ONNECTION If you want to use out-of-band management, want a replacement for a LAN connection, or want local console access, you need an asynchronous management port (AMP) connection. ANAGEMENT Out-of-band management allows you to manage the CyberSWITCH from some remote location without making use of the LAN or WAN connections. -
Page 14: Using An Amp Connection For Lan Replacement Or Local Console Access
QUICK START AMP C SING AN ONNECTION FOR Regardless of why you want to use an AMP connection, the cabling is the same. Use the supplied cable. To complete the cabling, refer to the following graphic and instructions. Connect one end of a Null Modem to your PC serial port. Connect the other end of the Null Modem to the CyberSWITCH’s serial port labeled Console. -
Page 15: The Isdn Connection
ISDN C ONNECTION No matter which LAN connection method you use, you must have an ISDN connection. This connection is your link to the outside world through ISDN lines. There is more than one ISDN connection method possible. The method you use depends on the country you live in, and whether or not you have an CyberSWITCH with the internal NT-1 option. -
Page 16: Cyberswitchs Without Internal Nt-1S
QUICK START SWITCH YBER S WITHOUT NTERNAL If you require an NT-1 and you purchase an CyberSWITCH without an internal NT-1, you will need to use an external NT-1 in your connection to the network. Issuing the ver command will tell you whether or not your CyberSWITCH has an internal NT-1. -
Page 17: Cyberswitchs Requiring Dsus
SWITCH YBER EQUIRING For countries that require DSUs (for example, Japan), your CyberSWITCH will not have an internal NT-1. You will need to use an external MJ and DSU in your connection to the network. To ISDN Source RJ-45 Connector ONNECTION NSTRUCTIONS If you are not using an CyberSWITCH with an internal NT-1:... -
Page 18: The Pots Connection
QUICK START POTS C ONNECTION The dual-line, Plain Old Telephone Service (POTS) feature allows one or both of the ISDN B- channels to alternatively be used with traditional phone equipment (for example, a phone, a fax, or an answering machine). When used with a LAN or AMP connection, this allows you to use one ISDN line for both data and voice. -
Page 19: The Power Connection
OWER ONNECTION Note: Before you plug in the CyberSWITCH, consider the following: • make sure the CyberSWITCH is well ventilated • insert the power cord into the wall last, after you attach the power supply and power cord to the CyberSWITCH. Connection instructions: As shown above, insert the power supply into outlet labeled DC Power on the back of the CyberSWITCH. -
Page 20: Basics
ASICS Once your cabling is complete, power on the CyberSWITCH simply by plugging its power cord into an electrical outlet. During the powering on sequence, the CyberSWITCH’s LED indicators provide valuable information. We provide you with instructions for “reading” the LED indicators. After powering on, but before putting the CyberSWITCH into normal operation, we recommend that you read the Release Notes for important information. -
Page 21: Safety Considerations
Insert the CD into the drive, change to the proper directory, and enter the following command at the DOS prompt: [CD-ROM drive]:\[platform directory][ISDN standard directory][option directory]> type REL_NOTE.TXT | more For example, if your CD-ROM is designated as drive D, you are installing is CSX150, using US ISDN standards and the IP/IPX option, you would use the following path: D:\CSX150\US\IPX>... -
Page 22: Changing The Baud Rate
QUICK START Use the following default values for your communication package: Baud rate Parity Data bits Stop bits Duplex HANGING THE The baud rate is changeable. The default rate performs well for configuration changes. A faster rate is useful, however, to download new software upgrades to your system. To change the baud rate through CFGEDIT: Select Physical Resources from the main menu. -
Page 23: Amp Connection
Note: Do NOT place more than one CyberSWITCH on a LAN with the default setting. With both having the same IP address, unpredictable results will occur. You may also Telnet in via the WAN connection, however, how to set it up with the default configuration will not be described in detail in this guide. -
Page 24: Upgrading Software
QUICK START For a more complex configuration, CFGEDIT is the comprehensive utility you may wish use to initially set up your system; you may use it later to make configuration changes as well. However, CFGEDIT is NOT dynamic. This means you will have to interrupt normal system operations in order to update configuration files. -
Page 25: Local Software Upgrade
The CSX150 CD contains installation, user documentation and upgrade files. The file structure is as follows: Directory <ROOT>\ \CSXDOCS\ \CSX156\JAPAN\ipipx \CSX156\JAPAN\ipipx.fr \CSX156\JAPAN\ipipx.x25 \CSX156\JAPAN\ipipxat \CSX156\JAPAN\ipipxat.fr \CSX156\JAPAN\ipipxat.pkt \CSX156\JAPAN\ipipx.pkt \CSX156\JAPAN\ipipxat.x25 For system upgrade, you will need to follow one of the above-mentioned upgrade paths (\product name\country\protocol or access package). -
Page 26: Local Upgrade Of The Second Stage Boot (Ssb)
QUICK START OCAL PGRADE OF THE ECOND To locally upgrade the second stage boot (SSB), follow these steps: Restart the CyberSWITCH. When “Waiting for Commands:” appears on the system screen, enter the following command: recover Wait for the system to respond with the prompt “Ready for Hex Download”. Using your communications program: •... -
Page 27: Remote Software Upgrade
EMOTE OFTWARE PGRADE Note: For security purposes, we recommend that you disable the TFTP Server after the upgrade is complete. To remotely upgrade the system, you are required to have a PC/workstation that is connected to the system’s network. It must have the following features: •... -
Page 28: Remote Upgrade Of The Operational Software (Osw)
QUICK START Using the TFTP client on the remote workstation, TFTP the recover1 file to the CyberSWITCH in binary mode. Be sure to use the file’s full pathname. The exact method to transfer varies, depending upon your TFTP client. At the system prompt, recover the SSB by issuing the following command: flash recover The system will ask you if you are sure you want to remotely recover the SSB, and warn you of the potential risk in case of a power failure while the SSB is being recovered. -
Page 29: Change Defaults To Secure System
• Using the MANAGE MODE command fileattr , verify that: • ADMIN has READ/WRITE access to CONFIG files • ADMIN has READ/WRITE access to OTHER files • Exit MANAGE MODE by typing exit <RET>. Using the TFTP client on the remote workstation, TFTP the UPGRADE.OSW file to the CyberSWITCH in binary mode. -
Page 30: Return Configuration To Factory Defaults
QUICK START Disable TFTP Server. Disable through Dynamic Management’s manage mode. This will secure important device information. Device information must be secure to prevent unauthorized access to the CyberSWITCH. To disable this access, enter the following command at the manage mode prompt: tftp change Then follow the on-screen instructions to disable the TFTP feature. -
Page 31: Physical Resource Configuration
HYSICAL ESOURCE ONFIGURATION Select Physical Resources from the main menu. Then, select Resource to display your CyberSWITCH’s resources. If you are not using the default switch type, press 1 to change the switch type. Configure the WAN line. Select Data Line from the Physical Resources menu. After you select to add a line you will be prompted for the line name. - Page 32 ONNECTIVITY VERVIEW The Small Office CyberSWITCH can communicate with various other CyberSWITCH products via a PPP connection. This connection can be used to transmit data and provide remote management of your remote systems with Telnet, TFTP and SNMP. We will describe how to set up a PPP connection with other CyberSWITCH systems.
- Page 33 Under Security, select System Options and Information, then under System Information: Set your System Name (Central). This matches up with Central device information configured on Remote. b. Set your System Secret (Central_S). This matches up with Central device information configured on Remote. Under Security, select Device Level Databases, select On-node Device Entries, then add a device where the Device Name (Remote) must match the system name on Remote.
- Page 34 QUICK START Under Security, select Device Level Databases, select On-node Device Entries, then add a device where the Device Name (Central) must match the system name on Central. When you add the device you must then enter the following information: Under ISDN Information make sure the ISDN Line Protocol is PPP.
- Page 35 Under Security, select Device Level Databases, select On-node Device Entries, then add a device where the Device Name (Remote) must match the system name on Remote. When you add the device you must then enter the following information: Under ISDN Information select ISDN Line Protocol, then select PPP. b.
- Page 36 QUICK START Return to the Options menu, select IP Routing, then select Static Route. You will have to configure a static route to the 199.2.2.0 LAN. When you configure a static route to a site that uses a unnumbered interface you must enter the device name of the next hop device, Central in this case.
- Page 37 Under Authentication you must: • Change CHAP Secret so that it matches Remote’s System secret (Remote_S). • Optional: Configure Calling Line Ids (if Calling Line Id security was enabled). d. Under IPX Information: • enable IPX • enable Make Calls for IPX data •...
- Page 38 QUICK START PPLE OUTER TO PPLE CSX1200 "Central" B-CHANNELS POWER B13 B15 B17 B19 B21 B23 B25 B27 SERVICE 10BASE - T B10 B12 B14 B16 B18 B20 B22 B24 B26 B28 Central's AppleTalk Configuration Network Range: 10-13 Zones: Central.Engineering (default) Central.Marketing "C ONFIGURATION FOR...
- Page 39 Under AppleTalk Port Information, configure a WAN UnNumbered port: • Select the WAN UnNumbered port type. d. Under AppleTalk Static Routes, configure a static route to Remote: • Enter Extended for Remote’s network type (the default). • Enter 45-50 as the destination network range (Remote’s network range). •...
- Page 40 QUICK START Under AppleTalk Port Information, configure a WAN UnNumbered port: • Select the WAN UnNumbered port type. d. Under AppleTalk Static Routes, configure a static route to Central: • Enter Extended for Central’s network type (the default). • Enter 10-13 as the destination network range (Central’s network range). •...
- Page 41 PECIAL EATURES POTS O ONFIGURING THE The dual-line, Plain Old Telephone Service (POTS) feature allows one or both of the ISDN B- channels to alternatively be used with traditional phone equipment, including faxes and answering machines. The CyberSWITCH can use both B-channels for data until a call is initiated or received. When a call comes up, the CyberSWITCH may then drop back to a single B-channel for data, and reserve the other B-channel for POTS use (such as voice or fax).
- Page 42 USER’S GUIDE POTS L ONFIGURING NFORMATION To use the POTS feature, you must configure a POTS line. POTS line information includes: the POTS line jack Id, the primary phone number (optional), and customization information (also optional). The section below describes configuring the POTS line information. Select Physical Resources from the main CFGEDIT menu.
- Page 43 From the displayed list, select the type of POTS priority you want for this device. You may select Preemption of 2nd B-Channel by POTS when both B-channels are active to this device. If you select this priority, one of the two active data calls to this device will be preempted to service an incoming/outgoing phone call.
- Page 44 USER’S GUIDE Select Mode of H/W Filtering from the bridging menu. Select your mode of hardware filtering from the displayed list. If you have selected Manual Mode: Select Bridge Filters from the bridging menu. b. Select Hardware Filters from the filters menu. Enter the MAC addresses you want to include.
- Page 45 ROUBLESHOOTING The front panel of the CyberSWITCH has several LED indicators. Refer to of the front panel. The Power indicator will remain lit while the unit is on. There is a series of three indicators: they light up indicating transmissions, receptions, or good link integrity on the 10Base-T port.
- Page 46 QUICK START D-CHAN LED status flashing (mostly off) flashing (mostly on) on solid * On DMS-100 and NI-1 switches, more than one data link is possible. • The CH-1 and CH-2 indicators signify activity along their respective B channel: CH-1 or CH-2 LED Status flashing on solid...
- Page 47 The table below provides an error description corresponding to the number of consecutive LED blinks: Number of Blinks * FSB: First Stage Boot; SSB: Second Stage Boot. ERVICE NDICATOR LINKS If the Service indicator blinks at any time during CyberSWITCH operation, access your administrative console (using the status command) for further information.
- Page 48 QUICK START NDEX Numerics 10Base2 (BNC) cabling 10BaseT direct cabling hub cabling indicator LED indicator address learning time-out alternate outbound alternate outbound (POTS) AMP connections auto mode (hardware filters) automatic TEIs battery replacement BNC cabling cabling AMP connections ISDN connections Nomad to PC connections POTS connection power connections...
-
Page 49: Cyberswitch
POTS call features configuration configuration requirements connection line information phone numbers speech service user information power connection power indicator real-time management mechanism dynamic management feature remote devices via PPP restart 20, 45 RX indicator S/T interface and the termination switches safety considerations security securing the system...
