S W
YSTEM ORKSHEETS
The worksheets included in this appendix will be helpful in configuring and managing your
system. They capture important network information. To see examples of completed worksheets,
refer to the Example Networks Guide.
Worksheets included in this appendix are:
1. Network Topology
• The Users or Remote Sites in your network.
• The telephone numbers associated with the Users or Remote Sites in your network.
• IP/IPX/AppleTalk information related to the Users or Remote Sites in your network.
• Bridge addresses related to the Users or Remote Sites in your network.
• Password information related to the Users or Remote Sites in your network.
2. System Details
CyberSWITCH in your network:
• The resource details for each adapter in your CyberSWITCH. Note the switch type.
• Details on each ISDN line attached to your CyberSWITCH. If a line has more than one
SPID, use an extra worksheet line to record that SPID and its associated directory number.
• Details on any configured accesses.
3. The Device Information Worksheet
worksheet for each of your network's remote devices.
4. Use the Bridging and Routing Information Worksheets
(from the Network Topology Worksheet) to ease the configuration process.
Worksheet. This worksheet identifies the following information:
Worksheet. This worksheet identifies the following information for each
identifies device information for one device. Complete a
to summarize your particular setup
