Current Destination Address Filter Configuration:
id DEST ADDRESS
--------------------------------------------------------
1 112233445566
(1) Add, (2) Change, (3) Delete a Destination Address Filter or <RET> to return to
the previous menu?
Your filter is now configured for this example. Remember, each type of filter for each operating
mode supports a different set of "forwarding actions." These are described in detail earlier in the
Bridge Filters section.
K C
NOWN ONNECT
The Known Connect List is a configurable list of all devices for which you want the system to
connect and forward bridged packets.
C K
ONFIGURING THE NOWN
Notes: Before beginning, be sure your system's resources are properly configured. This includes
resources, lines, and datalinks, if applicable. Refer to the
chapter.
In order to successfully dial out to a device on the CyberSWITCH's Known Connect List,
you must have the device information properly set up and the dial-out number(s)
stipulated. Refer to the
Databases chapter.
The dial out call must be made within a configured amount of time from its last connection.
This time is configurable through the Bridge Configuration menu's Spanning Tree
Parameters. The parameter for configuring the time is called the bridge age time. The
default bridge age time is 5 minutes. Refer to
default value.
U CFGEDIT
SING
1. From the Bridging Menu press (5) to configure the Known Connect List. The following screen
will then be displayed:
DEVICE LIST For CONNECT Filter
Device Name
----------------------
1) to Add a Device or press <RET> for previous menu? 1
Enter 1) to add a Device Name or <RET> to previous menu:
2. Press (1) to add a device to the Known Connect List.
3. Repeat step 2 for all devices you want included on this list.
ACTION
CONNECT
L
IST
C L
ONNECT IST
On-node Device Database
C
DISTRIBUTION LIST
John
Configuring Resources and Lines
section found in the Configuring Device Level
page 220 for instructions on changing the
Workgroup Remote Access Switch
A B
ONFIGURING DVANCED RIDGING

Known Connect List

235
