USER'S GUIDE
ipx trigreq [device]
Generates a triggered RIP/SAP update request to the specified device. You may use this
command to initiate an update request to synchronize with the routing database of a particular
WAN device.
ipx trigrip stats
Displays the triggered RIP statistics. Refer to
ipx trigsap stats
Displays the triggered SAP statistics. Refer to
ISDN U C
SAGE OMMANDS
The following commands are used to display and clear ISDN B-channel monitoring information.
isdn usage
Displays the following ISDN B-channel monitoring information:
• The number of ISDN B-channels available.
• The number of ISDN B-channels in use.
• The high-water mark for the number of ISDN B-channels in use.
• The value which the number of ISDN B-channels in use must meet or exceed in order to
cause an isdnUsageHigh SNMP trap to be generated by the system.
• The enabled status for the generation of the ISDN usage traps (isdnUsageHigh and isd-
nUsageNormal).
• The elapsed time since the monitoring of the high-water mark began.
This information can help you determine if additional lines and/or systems are necessary. For
example, the high water mark could be compared to the number of ISDN B channels available,
taking into consideration the elapsed time.
An example output from this command is as follows:
[System Name]> isdn usage
number of ISDN B channels available: 6
number of ISDN B channels in use:
high water mark:
isdnBChanUsage trap threshold:
generation of ISDN usage traps:
elapsed time:
isdn usage clear
Clears the B-channel high-water mark and elapsed time values. The purpose of this command
is to allow the user to reset the high-water mark to coincide with changes to the system and/
or the network or so that the user can monitor the high-water mark over desired time periods.
544 CyberSWITCH
IPX Triggered RIP
IPX Triggered SAP Statistics.
3
5
5
enabled
3 days, 4 hrs, 12 min, 38 sec
Statistics.
