Page 1 QuickSET Conﬁguration Guide for CSX200, CSX400, CSX400-DC, CSX500, HSIM-W6, and HSIM-W84 9032691-03...
Page 3: Fcc Notice
Only qualiﬁed personnel should perform installation procedures. Cabletron Systems reserves the right to make changes in speciﬁcations and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, ﬁrmware, or software described in this manual is subject to change without notice.
Page 4: Industry Canada Notice
Notice INDUSTRY CANADA NOTICE This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté...
Page 5 CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT IMPORTANT: THIS LICENSE APPLIES FOR USE OF PRODUCT IN THE FOLLOWING GEOGRAPHICAL REGIONS: CANADA MEXICO CENTRAL AMERICA SOUTH AMERICA BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems, Inc.
Page 6 Notice If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...
Page 7 CABLETRON SYSTEMS SALES AND SERVICE, INC. PROGRAM LICENSE AGREEMENT IMPORTANT: THIS LICENSE APPLIES FOR USE OF PRODUCT IN THE UNITED STATES OF AMERICA AND BY UNITED STATES OF AMERICA GOVERNMENT END USERS. BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems Sales and Service, Inc.
Page 8 Notice If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...
Page 9 CABLETRON SYSTEMS LIMITED PROGRAM LICENSE AGREEMENT IMPORTANT: THIS LICENSE APPLIES FOR THE USE OF THE PRODUCT IN THE FOLLOWING GEOGRAPHICAL REGIONS: EUROPE MIDDLE EAST AFRICA ASIA AUSTRALIA PACIFIC RIM BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems Limited (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (“Program”) in the package.
Page 10 Notice If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...
Page 11: Safety Information
CLASS 1 LASER TRANSCEIVERS THE FE-100F3 FAST ETHERNET INTERFACE MODULE, FPIM-05 AND FPIM-07 FDDI PORT INTERFACE MODULES, AND APIM-29 ATM PORT INTERFACE MODULE USE CLASS 1 LASER TRANSCEIVERS. READ THE FOLLOWING SAFETY INFORMATION BEFORE INSTALLING OR OPERATING THESE MODULES. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments.
Page 12: Declaration Of Conformity
Notice DECLARATION OF CONFORMITY Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives. Manufacturer Mr.
Page 13: Table Of Contents
CONFIGURATION WITH QuickSET Ethernet Configuration ... 3 Ethernet 1 and 2 Configuration Window ... 3 Local HSIM IP Address Window... 5 System Passwords... 7 Wide Area Module Configuration ... 9 Wide Area T1 Configuration Window ... 9 Wide Area E1 Configuration Window ... 11 Wide Area DI Configuration Window ...
Page 14 Contents Advanced Routing Configuration Window ... 45 Advanced IP Routing Settings... 46 Advanced IP Routing Options ... 46 NAT Settings Configuration Window ... 47 IP Host Map Window... 49 Modify IP Host Window ... 51 OSPF Redistribute Routes... 55 QuickSET Pull-Down Menus ... 57 File Menu ...
Page 15 Wide Area HDSL Time Slot Configuration Window... 99 Wide Area HDLC Time Slot Configuration Window ... 100 Line Coding... 101 General Configuration ... 102 DHCP Settings Configuration Window ... 102 Priority IP Queuing ... 104 Interfaces Window... 106 Alias Setup Button ... 106 Interface Backup Setup Button ...
Page 16 Contents OSPF Redistribute Routes... 134 IP Host Map Window... 136 Modify IP Host Window ... 137 IPX Routing Configuration Window... 138 IPX Host Map Window ... 138 QuickSET - Pull-Down Menus ... 141 File Menu ... 141 Create Configuration Text File ... 142 Firmware Upgrade Menu...
Page 17: Configuration With Quickset
Conﬁguration with QuickSET This manual is divided into two parts. The first part is the QuickSET NOTE configuration procedure for Version 1.xx.xx Firmware. The second part is the QuickSET configuration procedure for Version 2.xx.xx Firmware section This manual contains QuickSET conﬁguration procedures for the HSIM-W6, HSIM-W84, and CSX200, CSX400, and CSX500 CyberSWITCHes.
Page 18 Configuration with QuickSET If your system is connected to more than one network, you will see the Local User Networks window shown below in Figure 2. Use the scroll button to select the network connection that your QuickSET-conﬁgurable device is attached to. Click OK to select the network that your device is Figure 2 Local User Networks Window Normally, QuickSET automatically establishes a communication link with the device that you wish to conﬁgure.
Page 19: Ethernet Configuration
Ethernet Configuration Enter the IP address of the QuickSET-conﬁgurable device in the appropriate ﬁeld and the password if applicable (the default password is public). Click on the Create a Route... checkbox to create a route to this device on your PC. Click on the OK button and QuickSET locates the device on the network and displays the First Introductory window.
Page 20 Configuration with QuickSET Figure 4 Ethernet 1 and 2 Conﬁguration Window Displays the IP Address for the Local Ethernet Local Ethernet (1 and 2) IP Address — interface selected (Ethernet 1 or Ethernet 2). Place the cursor in this ﬁeld and type the preferred IP Address in Dotted Decimal Notation (DDN) format.
Page 21: Local Hsim Ip Address Window
Ethernet Configuration Local HSIM IP Address Window If you are conﬁguring an HSIM-W6 or -W84, you will see the Local HSIM IP Address Window shown below in Figure 5 in place of the Ethernet 1 and 2 Conﬁguration Window. Figure 5 Local HSIM IP Address Window Displays the IP Address for the Local HSIM Ethernet interface.
Page 22 Configuration with QuickSET The Secondary IPs window and Modify Secondary IP windows shown in Secondary IPs — Figure 6 below. The Secondary IPs window displays after clicking on the Secondary IPs... button on the Ethernet 1 and 2 Conﬁguration Window, and shows the list of current Secondary IP addresses.
Page 23: System Passwords
System Passwords The System Passwords window shown in on the Passwords button in the Ethernet 1 and 2 conﬁguration window, or the HSIM Local IP Address window. The system passwords used by QuickSET are the same as the Community Names of the device that are used in Local Management through a TELNET application.
Page 24 Configuration with QuickSET Figure 7 System Passwords Window When you have ﬁnished conﬁguring the system passwords, click on the OK button in the System Passwords window to return to the Ethernet 1 and 2 conﬁguration window, or the Local HSIM IP Address window.
Page 25: Wide Area Module Configuration
Wide Area Module Conﬁguration When conﬁguring WAN Interface Port Modules (WPIMs) with QuickSET , the Wide NOTE Area conﬁguration window that displays corresponds to the speciﬁc model of WPIM that is installed in your CyberSWITCH. The HSIM-W84 and CSX500 always employ four WPIM-T1 WAN interfaces.
Page 26 Configuration with QuickSET This section explains how to conﬁgure the Wide Area T1 interface using QuickSET. The line conﬁguration information shown must be supplied by your service provider. Factory default settings are in bold. The following deﬁnitions explain the ﬁelds in the T1 WAN conﬁguration window. Displays the T1 frame type.
Page 27: Wide Area E1 Configuration Window
Wide Area Module Configuration Wide Area E1 Conﬁguration Window The Wide Area (E1) conﬁguration window is shown in Figure 9 below. The following section explains how to conﬁgure the E1 WAN interface using QuickSET. The line conﬁguration information below, and on the following page must be supplied by your service provider.
Page 28: Wide Area Di Configuration Window
Configuration with QuickSET If you selected Frame Relay protocol, this ﬁeld displays Link Management Protocol — Q.933 Annex A, or T1.617 Annex D. The default is T1.617 Annex D. This ﬁeld is grayed out and not used for PPP. When you have completed conﬁguration, click on the Next>> button and go to the Wide Area Frame Relay Time Slot Configuration Window Wide Area PPP Time Slot Configuration...
Page 29: Di Functionality
DI Functionality The NI Port is connected to the T1 WAN connection. Any timeslot set to zero will Enable — pass (that timeslot) from the NI Port to the DI Port (see be local or come into the WPIM-DI through the NI Port. Data From DI —...
Page 30 Configuration with QuickSET WPIM-DI Site #1 Voice Clock: Clock: Loop Local The Tail Circuit (Figure 12, above) has the PBX as its timing source in site #1. The DI functionality for Site #1 is set to Data From DI. The DI functionality for Site #2 is set to Enable. The Transmit Clock Source must be set to Loop Timing at both sites for this conﬁguration.
Page 31 Wide Area Module Configuration Displays the signal level for the physical line. Set this to 0 dB unless the T1 Line BuildOut — service provider recommends another setting. The default setting for this ﬁeld is 0 dB. Click on the appropriate radio button for the following levels: 0 (Zero) dB, -7.5 dB, and -15 dB.
Page 32: Wide Area Synchronous Configuration Window
Configuration with QuickSET Wide Area Synchronous Conﬁguration Window The Wide Area Synchronous conﬁguration window is shown in Figure 14 Wide Area Synchronous Conﬁguration Window This section explains how to conﬁgure the Synchronous WAN port using QuickSET. The line conﬁguration information shown on the following page is determined by your service provider.
Page 33 Sync Port Type RS422 RS422 RS422 RS422 Displays your conﬁgured receive clock speed. The default setting for this Sync Clock Speed — ﬁeld is 64000 bits per second. The information necessary for you to set this ﬁeld is normally determined by the service provider. Select the down arrow button to make your selection from the list of clock speeds using the information provided by your service provider (if it is not listed, type the value in).
Page 34: Wide Area Dds Configuration Window
Configuration with QuickSET Wide Area DDS Conﬁguration Window The Wide Area DDS conﬁguration window is shown in explains how to conﬁgure the Wide Area DDS interface using QuickSET. Figure 15 Wide Area DDS Conﬁguration Window Table 2 shows the line conﬁguration information determined by your service provider. The factory default settings are in bold.
Page 35: Wide Area Hdsl Configuration Window
Displays the internal loopback as either Line Loop or No Loop. Line Loop is DDS Loop Back — reserved for network diagnostics only. The default setting is No Loop. Protocol — Displays the active protocol for the Wide Area interface. The Protocol panel lets you select either Frame Relay or Point-to-Point.
Page 36: Wide Area Time Slot Configuration Windows
Configuration with QuickSET Wide Area Time Slot Conﬁguration Windows The following section contains the following Wide Area Time Slot Conﬁguration windows: Wide Area Frame Relay Time Slot Configuration Window Wide Area PPP Time Slot Configuration Window Wide Area HDSL Time Slot Configuration Window Wide Area Frame Relay Time Slot Conﬁguration Window The Wide Area Frame Relay Time Slot conﬁguration window shown in Figure 17...
Page 37: Wide Area Ppp Time Slot Configuration Window
Wide Area Time Slot Configuration Windows Wide Area PPP Time Slot Conﬁguration Window The Wide Area PPP Time Slot conﬁguration window shown in Figure 18 displays when you click on the Next>> button in the Wide Area T1, or DI conﬁguration windows if you chose PPP as the WAN Protocol.
Page 38 Configuration with QuickSET Figure 20, below, shows the Line Coding window for T1, DI, and E1. The window displays Line Coding for any interface number. Figure 21, below, shows the Modify Line Coding window. Figure 20 Line Coding Window Figure 21 Modify Line Code Window QuickSET Configuration Guide...
Page 39 Wide Area Time Slot Configuration Windows The following section deﬁnes the Time Slots ﬁeld in the Wide Area PPP Time Slot conﬁguration window. A full line consists of 24 Time Slots (T1 and DI) or 31 Time Slots (E1) that are Time Slots —...
Page 40: Wide Area Hdsl Time Slot Configuration Window
Configuration with QuickSET Wide Area HDSL Time Slot Conﬁguration Window The Wide Area HDSL Time Slot conﬁguration window shown in Figure 22 displays when you click on the Next>> button in the Wide Area HDSL conﬁguration window. Figure 22 Wide Area HDSL Time Slot Conﬁguration Window The following section deﬁnes the Time Slots ﬁeld in the Wide Area HDSL Time Slot conﬁguration window.
Page 41 Wide Area Time Slot Configuration Windows Figure 23 Line Coding Window for HDSL Figure 24 Modify Line Coding window for HDSL When you have completed Wide Area HDSL Time Slot conﬁguration, click on the Next>> button, and go to the General Configuration window.
Page 42: General Configuration
Configuration with QuickSET General Conﬁguration The General Conﬁguration Window shown below in Priority IP Queueing functions for conﬁguration. DHCP Settings Conﬁguration Window The DHCP Settings conﬁguration window (shown in on the following page) displays after clicking on the DHCP Server... button in the General Conﬁguration window. The DHCP Settings conﬁguration window is used to conﬁgure the DHCP settings for the CyberSWITCH or HSIM.
Page 43 Wide Area Time Slot Configuration Windows The time the IP addresses in the pool can be used before they become invalid. Lease Timeout — Click on the pull-down menu to view a list of available leased timeout intervals. Selecting Never lets you to keep your DHCP assigned IP address until the next time you boot up your PC.
Page 44 Configuration with QuickSET Figure 27 DHCP Settings Window for HSIMs and CSX200 CyberSWITCH QuickSET Configuration Guide...
Page 45: Priority Ip Queuing
Wide Area Time Slot Configuration Windows Priority IP Queuing The Priority IP Queuing window (Figure 28, below), displays after clicking on the Priority Queuing button in the General Configuration window. Priority IP Queuing lets you prioritize packets generated from selected devices (speciﬁed by source IP Address), to ensure their delivery under peak WAN trafﬁc loads.
Page 46 Configuration with QuickSET Figure 29 Add Priority IP Address Window When you have completed General conﬁguration, be sure to save any changes you made. Click on the Next>> button in the General Configuration window to return to the Bridging and Routing Configuration Window.
Page 47: Bridging And Routing Configuration
Bridging and Routing Configuration Bridging and Routing Conﬁguration When you have collected all the necessary network information for the WAN, your CyberSWITCH or HSIM can be conﬁgured for inverse multiplexing or bridging and/or routing. Bridging and Routing Conﬁguration Window The ﬁrst Bridging and Routing conﬁguration window shown in Figure 30 displays after clicking on the Next>>...
Page 48 Configuration with QuickSET This ﬁeld allows you to specify bridging of trafﬁc. MAC Bridging — Figure 31 Bridging and Routing Conﬁguration Window for HSIM-W84 Spanning Tree Protocol — you to conﬁgure the CyberSWITCH or HSIM to use the Spanning Tree Protocol, which lets the remote device check for bridging loops, and other sites that use the Spanning Tree Protocol.
Page 49 This checkbox lets you disable the Proxy ARP function. Proxy ARP — Figure 32, below shows an example of Proxy ARP (Address Resolution Protocol). In this example, hosts A, and C need to communicate, and the only route is through host B as shown. The IP Addresses that deﬁne the link between hosts A and B use the same subnet number as the Ethernet LAN,(i.e., 192.168.54.0) through which hosts B and C communicate.
Page 50: Firewall Configuration Window
• Interface Number. When an IP Access Control List (ACL) is enabled on a router port, each packet forwarded out this port is ﬁrst checked against the ACL. If the address(es) of a packet match the address(es) in the ﬁrst ﬁlter in the list, the packet is permitted or denied as speciﬁed by that ﬁlter.
Page 51 Bridging and Routing Configuration Figure 34 Add Firewall Entry Window The Add Firewall Entry window (shown above in Figure 34) appears when you click on the Add Firewall button in the Firewall Conﬁguration Window. Use your mouse or the Tab key to navigate through the data ﬁelds.
Page 52 Configuration with QuickSET The following deﬁnitions explain the ﬁelds in the QuickSET Firewall conﬁguration window: The Access Control List number is a number assigned to a ACL (Access Control List) — speciﬁc list of sequence numbers. Sequence — A number assigned to individual access ﬁlters in an access list. As only one IP Access Control List can be applied to each port, a single list often includes several access control ﬁlters.
Page 53 Enter the port number in this ﬁeld to create an access control ﬁlter that applies only to Port — trafﬁc for a speciﬁc TCP or UDP service. TCP and UDP port numbers. Interface/ACL — The larger Interface/ACL window displays a list of Access Control List numbers organized by Interface Number.
Page 54: Bridging And Routing (Wan Frame Type) Configuration Window
The Bridging and Routing window displays ﬁelds for each interface number and its associated WAN Frame Type. Select the WAN Native frame type for router to router communication. Select the Encapsulated Ethernet or Encapsulated Ethernet SNAP frame types for router-to-bridge, or bridge-to-bridge communication.
Page 55 Bridging and Routing Configuration To change the WAN Frame Type information, scroll through the list of interface entries, and select the interface number you wish to modify by pressing the arrow button on the left side of the Interface # ﬁeld and press the Modify... button. The WAN Frame Type window displays. The WAN Frame Type window shown in Figure 37 below, allows you to select one of three frame...
Page 56: Routing Configuration Window
Displays the Subnet Mask assigned to the interface number. Subnet Mask — The Next Hop is the IP address of the IP port of the next router (in the direction of Next Hop — the subnet that you are deﬁning).
Page 57 Bridging and Routing Configuration This button allows you to add a route and to conﬁgure the CyberSWITCH or Add Route... — HSIM to forward only those packets from the speciﬁed route. Delete — This button deletes the route highlighted in the IP Routing Conﬁguration window. This button displays the Advanced Routing conﬁguration window.
Page 58: Ipx Routing Configuration
Configuration with QuickSET When Split Horizons is disabled (OFF) for any of the above protocols, all protocol information received on that port will be rebroadcast back out that port, for example, to allow other DLCIs (Data Link Connection Identiﬁers) on this port, that have not received these packets, to receive this information.
Page 59 Bridging and Routing Configuration The DLCI and Interface Number deﬁne the switched connection to the Telco central ofﬁce. Enter the remote WAN MAC address and the remote Router’s WAN Network number. Figure 41 IPX Host Map Window This section describes the ﬁelds in the IP Advanced conﬁguration window.
Page 60 Configuration with QuickSET This button displays the Add IPX Host window shown below in Figure 42. Use the scroll Add — button in the Interface Number window to ﬁnd a clear data ﬁeld. After entering your changes, click OK to return to the IPX Host Map window. Modify —...
Page 61: Advanced Routing Configuration Window
Bridging and Routing Configuration When you have ﬁnished making changes, click the OK button to exit the Modify IPX Host window. Click Done on the IPX Host Map window, and return to the (IP/IPX) Routing Conﬁguration window. When you have completed your conﬁguration, click on the Save button to save any conﬁguration changes you have made.
Page 62: Advanced Ip Routing Settings
Configuration with QuickSET Advanced IP Routing Settings This section describes the Advanced IP Routing Settings for Advanced Routing conﬁguration. Displays the active interface number. Interface # — Local WAN IP Address — Set this value only if you are going to use Numbered Mode. In numbered mode, the Local WAN IP address is the IP address of the WAN link leading into the Telco central ofﬁce.
Page 63: Nat Settings Configuration Window
Bridging and Routing Configuration NAT Settings Conﬁguration Window The Network Address Translation (NAT) Settings conﬁguration window (shown in Figure 46 below) displays after clicking on the NAT Settings... button in the Advanced Routing conﬁguration window. Figure 46 NAT Settings Conﬁguration Window The NAT Settings window is used to set up Network Address Translation on Ethernet ports 1 and 2.
Page 64 Configuration with QuickSET The following deﬁnitions explain the ﬁelds in the NAT Settings conﬁguration window. This pull-down menu is used to disable (OFF), Ethernet address translation to Interface # — or enable NAT for an interface number. To enable NAT click the pull-down menu button and select an interface number to run NAT through.
Page 65: Ip Host Map Window
The Redirector window Redirector Window — Redirector... button in the Advanced Routing conﬁguration window. The Redirector window is used to set up an IP address for a remote Dynamic Host Conﬁguration Protocol (DHCP) server. IP Host Map Window The IP Host Map window (Figure button in the Advanced Routing Conﬁguration Window.
Page 66 Configuration with QuickSET The IP Host Map is a database of remote IP hosts, deﬁned (generally) by their IP Address, and (more speciﬁcally) by their Interface Number and Data Link Connection Identiﬁer (DLCI). The DLCI and Interface Number deﬁne the switched connection to the Telco central ofﬁce. Figure 50 IP Host Map Window Use the Interface Number scroll button to select an Interface Number.
Page 67: Modify Ip Host Window
Bridging and Routing Configuration Modify IP Host Window The Modify IP Host window (Figure 52, below) appears when you click on the Modify button in the IP Host Map window. The host data displayed will correspond to the Interface Number displayed in the IP Host Map window.
Page 68 Configuration with QuickSET OSPF employs “ﬂooding” to exchange link-states with other routers. Any change in routing information is ﬂooded to all routers in the network. The use of “areas” puts a boundary on the explosion of link-state updates. All routers within an area will have the exact link-state database. Figure 53 OSPF Settings Window The OSPF Settings window shown in Figure 53...
Page 69 Bridging and Routing Configuration The OSPF Interface Conﬁguration Window shown in Figure 55 below, displays a database of Area Border Routers and relevant operating parameters. Deﬁnitions of these parameters are presented on the following pages. Figure 54 Add OSPF Area Window Figure 55 OSPF Interface Conﬁguration Window QuickSET Configuration Guide...
Page 70 Router Priority is used (with the Router ID) to select a Backup Designated Router Priority — Router, and a Designated Router. The range of Router Priority is from 0 to 255, where 255 is the highest. The highest router ID is the highest router IP Address. Class C addresses are the highest.
Page 71: Ospf Redistribute Routes
If a neighboring router has become inactive (Hello packets have not been seen for Poll Interval — [Router Dead] seconds, it may still be necessary to send Hello packets to the dead neighbor. These Hello packets will be sent at the reduced rate [Poll Interval], which should be much larger than Hello interval.
Page 72 Configuration with QuickSET The Add route window (shown below in OSPF Redistribute Routes window. Enter the new values for the route to be redistributed and click OK when you have ﬁnished. The IP Route Warning message (shown below in the any of the parameters (i.e., subnet mask, Destination, or Next Hop) deﬁning the static route in the Add Route window.
Page 73: Quickset Pull-Down Menus
QuickSET Pull-Down Menus Figure 60 Modify Route Window You will return to the OSPF Redistribute Routes window. You may select another route to Add, Delete, or Modify, or Click Done to exit OSPF Redistribute Routes. QuickSET Pull-Down Menus The File, Firmware Upgrade, and Runtime Conﬁguration QuickSET pull-down menus allow you to store and restore conﬁgurations, initiate TFTP/BootP Services, and conﬁgure Compression and Congestion Settings for your CyberSWITCH or HSIM.
Page 74 Configuration with QuickSET Figure 62 Store Conﬁguration Window The Restore Conﬁguration window shown in Figure 63 displays after Restore Conﬁguration — clicking on the File pull-down menu and selecting Restore Conﬁguration at the top of any QuickSET conﬁguration window. The Restore Conﬁguration window allows you to load your stored conﬁguration from a drive into QuickSET where it can be loaded into your CyberSWITCH or HSIM and saved Figure 63 Restore Conﬁguration Window...
Page 75: Firmware Upgrade Menu
QuickSET Pull-Down Menus The Save As window shown in Figure 64 displays when you Create Conﬁguration Text File — click on the File pull-down menu and select Create Conﬁguration Text File at the top of any QuickSET conﬁguration window. Figure 64 The Save As Window This function lets you create a text ﬁle of your conﬁguration parameters.
Page 76 Configuration with QuickSET The TFTP/BootP Services window allows you to access a TFTP (Trivial File Transfer Protocol) server or BootP server to download the latest version of CyberSWITCH or HSIM ﬁrmware. Below are the modiﬁable ﬁelds of the TFTP /BootP Services window: The IP Address ﬁeld shows the IP Address of the device being upgraded.
Page 77: Runtime Configuration Menu
QuickSET Pull-Down Menus Runtime Conﬁguration Menu This section describes the pull-down menu options available from the Runtime Conﬁguration menu as shown in Figure Figure 67 Runtime Conﬁguration Menu Compression and Congestion Window The Compression and Congestion window shown in Figure 68 displays after you click on the Runtime Configuration pull-down menu and select Compression &...
Page 78 Configuration with QuickSET The Compression and Congestion window lets you to enable data compression on each interface. Data compression reduces the size of the data being sent on a WAN link, effectively extending the link bandwidth. The type of compression in use (hardware or software) is displayed in the Compression and Congestion window title bar.
Page 79: Set Device Time And Date
QuickSET Pull-Down Menus Displays the Excess Burst size, which is the maximum amount of data by Excess # Burst — which a user can exceed the Committed Burst size. This data is not guaranteed to be passed by the network. Throughput —...
Page 80: Quickset Configuration (Firmware Version 02.Xx.xx)
Configuration with QuickSET QuickSET Conﬁguration (Firmware Version 02.XX.XX) The ﬁrmware version number appears on the ﬁrst QuickSET screen in the area that is highlighted Figure 71 below. If your QuickSET screen shows ﬁrmware versions 02.00.xx or greater, your QuickSET conﬁguration instructions begin here. Firmware Version Number Figure 71 QuickSET Screen Showing Firmware Version Number QuickSET Configuration Guide...
Page 81 QuickSET Configuration (Firmware Version 02.XX.XX) If your system is connected to more than one network, you will see the Local User Networks window shown below in Figure 72. Use the scroll button to select the network connection that your QuickSET capable device is attached to. Click OK to select the network that your QuickSET-capable device is on.
Page 82: Ethernet Port Configuration
Configuration with QuickSET Ethernet Port Conﬁguration This section explains how to conﬁgure the Ethernet 1 and 2 ﬁelds (or Local HSIM Address) using QuickSET. Ethernet 1 and 2 Conﬁguration Window The Ethernet 1 and 2 conﬁguration window, shown in Figure 74, displays after clicking on the Next>>...
Page 83 Ethernet Port Configuration Figure 75 Local HSIM IP Address Window This section describes each of the ﬁelds on the Ethernet 1 and 2, and Local HSIM IP Address conﬁguration windows. Displays the IP Address for the Local HSIM Ethernet interface. Place Local HSIM IP Address —...
Page 84 Configuration with QuickSET The Secondary IPs window shown in Figure 76 displays after clicking on the Secondary IPs — Secondary IPs... button, and shows the list of current Secondary IP addresses. Figure 76 QuickSET Secondary IPs and Modify Windows CyberSWITCHes and HSIMs can support multiple IP Subnets, therefore, there can be multiple Secondary IP Addresses assigned to an Ethernet interface.
Page 85 Ethernet Port Configuration The System Passwords window shown in Figure 77 displays after System Passwords — clicking on the Passwords button in the Ethernet 1 and 2 conﬁguration window, or the Local HSIM IP Address window. The system passwords used by QuickSET are the same as the Community Names that are used in Local Management through a TELNET application.
Page 86: Wide Area - 1 And 2 Configuration Windows
Configuration with QuickSET The following deﬁnitions explain the ﬁelds in the System Passwords window. This access level allows reading of device parameters not including Read Only Access — system passwords. Place the cursor in this ﬁeld and type the new system password. Retype the system password in the Conﬁrm Password ﬁeld below the Read Only Access ﬁeld.
Page 87: Wide Area T1 - Configuration Window
Refer to the appropriate section listed below to conﬁgure your Wide Area 1 or 2 interface: Wide Area T1 - Configuration Window Wide Area E1 - Configuration Window Wide Area DI - Configuration Window Wide Area Synchronous - Configuration Window Wide Area DDS - Configuration Window Wide Area HDSL - Configuration Window Wide Area ISDN Configuration Window...
Page 88 Configuration with QuickSET Displays the signal level for the physical T1 line. Set this to 0 dB unless the T1 Line BuildOut — service provider recommends another setting. The default setting for this ﬁeld is 0 dB. The following options are available for this setting: 0 dB, -7.5 dB, and -15 dB. T1 Line Coding —...
Page 89 Wide Area - 1 and 2 Configuration Windows Figure 79 DLCIs and Add DLCI Windows When you have completed Wide Area T1 conﬁguration, click on Next>>, and go to the Wide Area Time Slot Configuration Windows section, for the appropriate time slot window. QuickSET Configuration Guide...
Page 90: Wide Area E1 - Configuration Window
Configuration with QuickSET Wide Area E1 - Conﬁguration Window The Wide Area (E1) conﬁguration window is shown in Figure 80, below. The following section explains how to conﬁgure the E1 WAN interface using QuickSET. Figure 80 Wide Area E1 Conﬁguration Window The following deﬁnitions explain the ﬁelds in the Wide Area E1 conﬁguration window.
Page 91 Wide Area - 1 and 2 Configuration Windows High Level Data Link Control lets you select either Full or Fractional mode for all or half of the time slots (for a single interface number and alias). Point-to-Point protocol lets you select an interface number for each time slot.
Page 92: Wide Area Di - Configuration Window
Configuration with QuickSET Wide Area DI - Conﬁguration Window The Wide Area (DI) conﬁguration window is shown in Figure 82 Wide Area DI Conﬁguration Window The line conﬁguration information given below and on the following pages must be supplied by your service provider.
Page 93 WPIM-DI Site #1 Voice Clock: Clock: Loop Loop Telco Timing — The following conﬁguration, shown above in system clock source is supplied by the Telco cloud between the two sites. The DI functionality option is set to Enable for both WPIM-DIs. Transmit Clock Source must be set to Loop Timing at both sites for this conﬁguration.
Page 94: Configuration Information
Configuration with QuickSET WPIM-DI Site #1 Voice Clock: Clock: Local Loop For the Internal Timing conﬁguration shown in Internal Timing — source is the WPIM-DI at Site # 1. DI functionality is set to Enable for both sites. Transmit Clock Source must be set to Local Timing for Site #1, and to Loop Timing for Site #2.
Page 95: Dlci Setup Button
Wide Area - 1 and 2 Configuration Windows Displays the active protocol for the Wide Area interface. The Protocol panel lets you Protocol — select one of four protocols: Point-to-Point, HDLC (High Level Data Link Control), Frame Relay Point-to-Point, Frame Relay Point-to-Multipoint. High Level Data Link Control lets you select either Full or Fractional mode for all or half of the time slots (for a single interface number and alias).
Page 96: Wide Area Synchronous - Configuration Window
Configuration with QuickSET Wide Area Synchronous - Conﬁguration Window The Wide Area Synchronous conﬁguration window is shown in Figure 87 Wide Area Synchronous Conﬁguration Window The next section explains how to conﬁgure the Synchronous WAN port using QuickSET. The following deﬁnitions explain the ﬁelds in the Synchronous WAN conﬁguration window. Sync Port Type —...
Page 97 Sync Port Type RS422 RS422 Displays your conﬁgured receive clock speed. The default setting for this Sync Clock Speed — ﬁeld is 64000 bits per second. Select the down arrow button to make your selection from the list of clock speeds (if it is not listed, type the value in). Sync Flow Control —...
Page 98 Configuration with QuickSET Figure 88 DLCIs Window Figure 89 Add DLCI Window When you have completed Wide Area Synchronous conﬁguration, click on the Next>> button, and go to the Interfaces Window section of this procedure. QuickSET Configuration Guide...
Page 99: Wide Area Dds - Configuration Window
Wide Area DDS - Conﬁguration Window The Wide Area DDS conﬁguration window is shown in how to conﬁgure the Wide Area DDS interface using QuickSET. Figure 90 Wide Area DDS Conﬁguration Window Table 6, below, shows the line conﬁguration information normally determined by your service provider.
Page 100 Configuration with QuickSET Displays the DDS clock source. The selections for this ﬁeld are either DDS Clock Source — Loop-Timing or Local-Timing. The Loop-Timing setting allows the device to receive its timing information from the service provider. The Local-Timing setting allows the device to generate its timing information internally.
Page 101: Wide Area Hdsl - Configuration Window
Wide Area - 1 and 2 Configuration Windows Figure 92 Add DLCI Window When you have completed Wide Area DDS conﬁguration, click on the Next>> button, and go to Interfaces Window section of this guide. Wide Area HDSL - Conﬁguration Window The Wide Area HDSL conﬁguration window is shown in Figure 93, below.
Page 102 Configuration with QuickSET This section describes the ﬁelds in the Wide Area HDSL conﬁguration window. Displays the HDSL Transmit Clock Source. Click on the radio HDSL Transmit Clock Source — button to select either the Slave or Master option. The default setting is Slave. Protocol —...
Page 103: Wide Area Isdn - Configuration Window
Wide Area - 1 and 2 Configuration Windows Figure 95 Add DLCI Window When you have ﬁnished Wide Area HDSL conﬁguration, click on the Next>> button, and go to the Wide Area Time Slot Configuration Windows section for the appropriate time slot window. Wide Area ISDN - Conﬁguration Window The Wide Area ISDN Conﬁguration Window shown is in Figure...
Page 104: Isdn Configuration Parameters
Configuration with QuickSET ISDN Conﬁguration Parameters The following deﬁnitions explain the ﬁelds in the Wide Area ISDN conﬁguration window: The ﬁrmware supports the following telephone switch Telephone Company Switch Type — types: AT&T 5ESS (with custom software), Northern Telecom DMS-100 (with custom software), or the other telephone company switches that support NI-1 (National ISDN-1 Service).
Page 105 Wide Area - 1 and 2 Configuration Windows Figure 97 Warning Message Use the Proﬁle Wizard window shown in Figure 98 below, to enter the number of Primary Proﬁles you require. Figure 98 First ISDN Proﬁle Wizard window QuickSET Configuration Guide...
Page 106 Configuration with QuickSET The second ISDN Proﬁle Wizard window, shown below in Figure 99, lets you select the number of secondary proﬁles required for each primary proﬁle. Use the scroll buttons in the Primary Proﬁle # window to select each primary proﬁle by number. Click OK when you have ﬁnished. Figure 99 Second ISDN Proﬁle Wizard Window The Create Settings message shown below in Figure...
Page 107: Modify Profile Button
The Modify Proﬁle window shown below in Proﬁles button on the ISDN Conﬁguration window. Figure 101 ISDN Proﬁle Wizard Modify Proﬁle Window Modify Proﬁle Button The Modify Proﬁle button will display the Modify Proﬁle window shown in The Modify Proﬁle window lets you modify the individual parameters of the proﬁle currently displayed in the ISDN Proﬁles window.
Page 108 Configuration with QuickSET Enter the Caller ID number of a remote line that you wish to allow to call in to Dial-In Number — your ISDN Interface. All incoming calls are veriﬁed against the Caller ID number. Caller ID requires that Caller ID service be provided by your telephone company. Caller ID service is not automatically provided - you will have to subscribe to it in addition to your normal ISDN service.
Page 109 One of the routers (referred to as the authenticator) challenges the other router, (referred to as the peer), by generating a random number and sending it, along with the system name. The peer then applies a one-way hash algorithm to the random number, and returns this encrypted information along with the system name.
Page 110 Configuration with QuickSET Then the other router, referred to as the authenticator, checks the peer’s password against the remote router’s password and returns acknowledgment. When you select PAP, you will need to supply your Local Name and Local to Remote Password, and the Remote Name and Remote to Local Password.
Page 111: Wide Area Time Slot Configuration Windows
Wide Area Time Slot Configuration Windows Wide Area Time Slot Conﬁguration Windows This section contains the following Wide Area Time Slot Conﬁguration windows: Wide Area Frame Relay Time Slot Configuration Window Wide Area PPP Time Slot Configuration Window Wide Area HDSL Time Slot Configuration Window Wide Area HDLC Time Slot Configuration Window Wide Area Frame Relay Time Slot Conﬁguration Window The Wide Area Frame Relay Time Slot conﬁguration window shown in...
Page 112 Configuration with QuickSET Figure 104 Frame Relay Time Slot conﬁguration window -E1 Clicking the Line Coding button displays the Line Coding window. For an explanation of line coding functions, see Line Coding section. When you have completed Wide Area Frame Relay Time Slot conﬁguration and Line Coding, click on the Next>>...
Page 113: Wide Area Ppp Time Slot Configuration Window
Wide Area Time Slot Configuration Windows Wide Area PPP Time Slot Conﬁguration Window The Wide Area PPP Time Slot conﬁguration window shown in Figure 105 displays when you click on the Next>> button in the Wide Area T1 or DI conﬁguration windows if you chose PPP as the WAN Protocol.
Page 114 Configuration with QuickSET The following section deﬁnes the Wide Area PPP Time Slot conﬁguration windows. A full line consists of 24 Time Slots (T1 and DI) or 31 Time Slots (E1) that are Time Slots — each capable of up to 64 Kbps throughput. Using the PPP Protocol, up to 24 interfaces (T1 and DI) or 31 interfaces (E1) can be assigned to the WAN link.
Page 115: Wide Area Hdsl Time Slot Configuration Window
Wide Area Time Slot Configuration Windows Wide Area HDSL Time Slot Conﬁguration Window The Wide Area HDSL Time Slot conﬁguration window shown in Figure 107 displays when you click on the Next>> button in the Wide Area HDSL conﬁguration window. Figure 107 Wide Area HDSL Time Slot Conﬁguration Window The following section deﬁnes the Wide Area HDSL Time Slot conﬁguration window.
Page 116: Wide Area Hdlc Time Slot Configuration Window
Configuration with QuickSET Wide Area HDLC Time Slot Conﬁguration Window The Wide Area HDLC Time Slot conﬁguration window shown in Figure 108 below, displays when you click on the Next>> button in the Wide Area T1, E1, or DI conﬁguration windows if you chose HDLC as the WAN Protocol.
Page 117: Line Coding
Wide Area Time Slot Configuration Windows Line Coding Clicking the Line Coding button on any wide area time slot conﬁguration window displays the Line Coding window shown in Figure 109 below. Clicking the Automatically Match Line Coding for each Interface check box sets all time slots assigned to a speciﬁc interface number to the selected coding simultaneously.
Page 118: General Configuration
Configuration with QuickSET General Conﬁguration The General Conﬁguration window is shown below in Figure 110. Figure 110 General Conﬁguration Window DHCP Settings Conﬁguration Window The DHCP Settings conﬁguration window shown in Figure 111 below, displays after clicking on the DHCP Server... button in the General Conﬁguration window. Figure 111 DHCP Settings Conﬁguration Window QuickSET Configuration Guide...
Page 119 General Configuration The DHCP Settings conﬁguration window is used to conﬁgure DHCP settings for the CyberSWITCH or HSIM. If you are conﬁguring an HSIM or CSX200, you will see the window shown below in Figure 112. Figure 112 DHCP Settings Window for HSIM, CSX200 QuickSET Configuration Guide...
Page 120: Priority Ip Queuing
Configuration with QuickSET The following deﬁnitions explain the ﬁelds in the DHCP Settings conﬁguration window: Check this box to allow the CyberSWITCH or HSIM to act as a DHCP Server is Enabled — DHCP server. DHCP IP Address Pool — A set of contiguous IP addresses that can be assigned by the CyberSWITCH to devices requesting an IP address.
Page 121 General Configuration Figure 113 Priority IP Queuing Screen To conﬁgure this feature, click the ADD IP button, and the Add Priority IP Address screen, shown Figure 114, appears. Enter the IP Address(es) that are to receive priority treatment in the IP Address window.
Page 122: Interfaces Window
Configuration with QuickSET Interfaces Window The Interfaces Window shown below in Figure 115, displays after clicking the Next button to exit any General Conﬁguration. Figure 115 Interfaces Window Alias Setup Button Click the Alias Setup button to display the Interface Alias window shown in Figure 116 below.
Page 123: Interface Backup Setup Button
General Configuration Interface Backup Setup Button The Interface Backup Setup button displays the Interface Backup Conﬁguration Window shown Figure 117 below. The Interface Backup Conﬁguration Window lets you set up the parameters for a backup WPIM interface (usually an ISDN interface). Figure 117 Interface Backup Conﬁguration Window The connection parameters of the highlighted interface are displayed in the center of this window.
Page 124 Configuration with QuickSET Figure 118 Modify Backup Window The following are deﬁnitions of Dial-Up Settings parameters: Time to Connect lets you conﬁgure the seconds to wait, before attempting to Time to Connect — switch over to the back-up interface. The default is zero. Allowed values are in increments of ﬁve seconds, to a maximum of 10,000 seconds.
Page 125: Dial-Up Settings Button
General Configuration Dial-Up Settings Button The Dial-up Settings button displays the Dial-up Settings Window, shown below in Figure 119. This window lets you set up the Idle Timeout parameter for each Dial-Up interface. Figure 119 Dialup Settings and Modify Windows The Modify Dial-up Setting window lets you modify a Dial-up Setting entry highlighted in the Dial-up Settings window.
Page 126: Spoofing Settings Button
Configuration with QuickSET Spooﬁng Settings Button Spooﬁng is a cost saving innovation. Spooﬁng uses a router on the LAN to simulate “keep-alive” packets sent across a WAN link to keep the connection open. Generating these packets locally lets the connection close down, saving the cost of keeping a circuit alive when there is no trafﬁc.
Page 127: Bridging And Routing - Configuration
Bridging and Routing - Configuration Bridging and Routing - Conﬁguration Bridging and Routing Window The ﬁrst Bridging and Routing window, shown below in Figure 122 displays when you click the Next button on the Interfaces window. (Figure 123 shows the HSIM-W84 Bridging and Routing window).
Page 128 Configuration with QuickSET This ﬁeld allows you to specify whether the device bridges trafﬁc. Click on the MAC Bridging — check box to turn MAC Bridging on. Figure 123 HSIM-W84 Bridging and Routing Window Spanning Tree Protocol — you to conﬁgure the device to use the Spanning Tree Protocol, which lets the remote device check for bridging loops, and other sites that use the Spanning Tree Protocol.
Page 129 This checkbox lets you disable the Proxy ARP function. Proxy ARP — Figure 32, below shows an example of Proxy ARP (Address Resolution Protocol). In this example, hosts A, and C need to communicate, and the only route is through host B as shown. The IP Addresses that deﬁne the link between hosts A and B use the same subnet number as the Ethernet LAN,(i.e., 192.168.54.0) through which hosts B and C communicate.
Page 130: Firewall Window
• Interface Number. When an IP Access Control List (ACL) is enabled on a router port, each packet forwarded out this port is ﬁrst checked against the ACL. If the address(es) of a packet match the address(es) in the ﬁrst ﬁlter in the list, the packet is permitted or denied as speciﬁed by that ﬁlter. If there is no match, the packet is checked against the second ﬁlter, and so on, until a match is found, or until the packet...
Page 131 Bridging and Routing - Configuration Figure 125 Firewall Window Figure 126 Add Firewall Entry Window QuickSET Configuration Guide...
Page 132 Configuration with QuickSET The Modify Firewall Entry window (shown below in Figure 127) appears when you click on the Modify button on the Firewall Entries panel (upper half) of the Firewall Conﬁguration Window. Use your mouse or the Tab key to navigate through the data ﬁelds. Click OK when you have ﬁnished entering the data.
Page 133 Bridging and Routing - Configuration Figure 129 Modify ACL Window The following deﬁnitions explain the ﬁelds in the QuickSET Firewall conﬁguration window: ACL (Access Control List) — The Access Control List number is a number assigned to a speciﬁc list of sequence numbers. Sequence —...
Page 134 Configuration with QuickSET Displays the mask for the Destination IP address speciﬁed in the Dest IP ﬁeld. To Dest Mask — set the mask for the speciﬁed destination IP address, place the cursor in the Dest Mask ﬁeld and type the mask. Protocol —...
Page 135: Second Bridging And Routing Window
The Bridging and Routing window displays ﬁelds for each interface number and its associated WAN Frame Type. Select the WAN Native frame type for router to router communication. Select the Encapsulated Ethernet or Encapsulated Ethernet SNAP frame types for router-to-bridge, or bridge-to-bridge communication.
Page 136 Configuration with QuickSET The WAN Frame Type window shown in Figure 131 allows you to select one of three frame types to be used over the WAN for each interface: Native WAN, Encapsulated Ethernet, and Encapsulated Ethernet SNAP. Select the WAN Frame Type that you wish to enable by clicking the appropriate radio button. When you are done, click the OK button.
Page 137: Routing Configuration Window
Subnet Mask — Displays the Subnet Mask assigned to the interface number. The Next Hop is the IP address of the IP port of the next router (in the direction of Next Hop — the subnet that you are deﬁning).
Page 138: Advanced Options Window
To set up a default route in “Numbered Mode” communication, click the Default Route button. The IP Subnet 000.000.000.000, and Subnet Mask 255.255.255.255 will automatically be entered. Then use the NEXT HOP data ﬁeld to enter the IP Address of the router you wish to designate as the default route.
Page 139: Split Horizons Window
Routing Configuration Window Below are descriptions of the ﬁelds in the advanced IP Routing settings window: Displays the active Interface Number. Interface Number — Alias — This an alias name that you create for the interface number for convenience. This is the IP Address of the WAN link (identiﬁed by Interface Local WAN IP Address —...
Page 140: Advanced Ip Routing Options
Configuration with QuickSET When Split Horizons is OFF (disabled) for any of the above protocols, all protocol information received on that port will be rebroadcast back out that port, for example, to allow other DLCIs (Data Link Connection Identiﬁers) on this port, that have not received these packets, to receive this information.
Page 141 Routing Configuration Window Figure 136 NAT Settings Window Add Proxy... — Allows you to add NAT proxy servers. Click the Add Proxy... button and an Add NAT Proxy Server window (Figure 137 below) will appear. Enter an IP Address, and select a Port number/type and a Protocol for each server entry.
Page 142 Configuration with QuickSET Selecting this function (see Figure 138, below) enables the sending and RIP Settings — receiving of Routing Information Protocol packets. Routing Information Protocol is used in IP for broadcasting open path information between routers to keep routing tables current. Figure 138 Disable/Enable RIP Window Clicking the Modify button displays the Modify RIP window shown below in Figure...
Page 143: Routing Information Protocol Options
Routing Configuration Window Routing Information Protocol Options The following options are available in the Modify RIP panel: do not send any Routing Information Protocol packets from this interface. Do Not Send — Do Not Receive — do not allow any Routing Information Protocol packets to be received by this interface.
Page 144: Next Hop
Entries in RIP-2 routing tables always have a Next Hop ﬁeld. The Next Hop is the IP address of the next router along the path to the destination. The purpose of the Next Hop in the routing table is to prevent packets from being routed through extra hops in the system.
Page 145: Authentication
RIP-1 routers will never receive RIP-2 routes. This feature is useful when the correct use of an advertised route depends on knowing the precise subnet mask, which would be ignored by a RIP-1 router. Compatibility Switch A compatibility switch is necessary for two reasons. First, there are implementations of RIP-1 in the ﬁeld that do not follow RFC1058, and second, the use of multicasting would prevent RIP-1...
Page 146: Ospf Settings
Configuration with QuickSET * If the router is not conﬁgured to authenticate RIP-2 messages, then RIP-1 and unauthenticated RIP-2 messages will be accepted. Authenticated RIP-2 messages will be discarded. If the router is conﬁgured to authenticate RIP-2 messages, then RIP-1 messages and RIP-2 messages which pass authentication testing will be accepted.
Page 147 Routing Configuration Window OSPF employs “ﬂooding” to exchange link-states with other routers. Any change in routing information is ﬂooded to all routers in the network. The use of “areas” puts a boundary on the explosion of link-state updates. All routers within an area will have the exact link-state database. Figure 140 OSPF Settings Window The OSPF Settings window shown in Figure 140...
Page 148 Configuration with QuickSET Use the Add OSPF Area window (shown in Figure 141, below) to add an area to the database. The Delete Area button will delete the area highlighted in the database in the OSPF Settings Window. The OSPF Interface Conﬁguration window shown in Figure 142 below, displays a database of Area Border Routers and relevant operating parameters.
Page 149 Router Priority is used (with the Router ID) to select a Backup Designated Router Priority — Router, and a Designated Router. The range of Router Priority is from 0 to 255, where 255 is the highest. The highest router ID is the highest router IP Address. Class C addresses are the highest.
Page 150: Ospf Redistribute Routes
If a neighboring router has become inactive (Hello packets have not been seen for Poll Interval — [Router Dead] seconds, it may still be necessary to send Hello packets to the dead neighbor. These Hello packets will be sent at the reduced rate [Poll Interval], which should be much larger than Hello interval.
Page 151 Routing Configuration Window The Add route window (shown below in Figure 145) appears when you click the Add button on the OSPF Redistribute Routes window. Enter the new values for the route to be redistributed and click OK when you have ﬁnished. Figure 145 Add Route The IP Route Warning message (shown below in Figure...
Page 152: Ip Host Map Window
Configuration with QuickSET The Modify Route window (shown in Figure 147 below) appears when you click the Modify button on the OSPF Redistribute Routes window. This window is used to modify an existing route in the redistribute routes data base. Figure 147 Modify Route Enter the new data into the respective windows, and click OK when you have ﬁnished.
Page 153: Modify Ip Host Window
Routing Configuration Window Figure 149 Add IP Host and Modify IP Host Windows The IP Host Map is a database of remote IP hosts, deﬁned (generally) by their IP Address, and (more speciﬁcally) by their Interface Number and Data Link Connection Identiﬁer (DLCI). The DLCI and Interface Number deﬁne the switched connection to the Telco central ofﬁce.
Page 154: Ipx Routing Configuration Window
Interface Number and Data Link Connection Identiﬁer (DLCI). The DLCI and Interface Number deﬁne the switched connection to the Telco central ofﬁce. Enter the remote WAN MAC address and the remote Router’s WAN Network number. Figure 150 IPX Host Map Window...
Page 155 Routing Configuration Window This section describes the ﬁelds in the IPX Advanced conﬁguration window. Displays the active interface number (a two-digit decimal number related to the Interface # — Frame Relay Time Slot). Alias — Displays an alias name that you assign to the active Interface Number. Displays the Data Link Connection Identiﬁer.
Page 156 Configuration with QuickSET This button deletes the entry highlighted in the IPX Host Map window. Delete Host — Figure 152 Add IPX Host Window When you have ﬁnished making changes, click the OK button to exit the IPX Host Map window and return to the (IP/IPX) Routing Conﬁguration window.
Page 157: Quickset - Pull-Down Menus
QuickSET - Pull-Down Menus QuickSET - Pull-Down Menus The File, Firmware Upgrade, and Runtime Conﬁguration QuickSET pull-down menus allow you to store and restore conﬁgurations, initiate TFTP/BootP Services, and conﬁgure Compression and Congestion Settings for your CyberSWITCH or HSIM. File Menu This section describes the File Menu pull-down menu options shown below in Figure 153.
Page 158: Create Configuration Text File
Configuration with QuickSET The Restore Conﬁguration window shown in Figure 155 below, Restore Conﬁguration — displays when you click on the File pull-down menu and select Restore Conﬁguration at the top of any QuickSET conﬁguration window. The Restore Conﬁguration window lets you load your stored conﬁguration into QuickSET where it can be loaded into your device and saved.
Page 159: Firmware Upgrade Menu
QuickSET - Pull-Down Menus Firmware Upgrade Menu This section describes the pull-down menu option available from the Firmware Upgrade menu as shown in Figure 156. Figure 156 Firmware Upgrade Menu The TFTP/BootP Services window shown in Figure 157 below, TFTP/BootP Services — displays after clicking on the Firmware Upgrade pull-down menu and selecting TFTP/BootP Services at the top of any QuickSET conﬁguration window.
Page 160: Runtime Configuration Menu
Configuration with QuickSET This section describes the modiﬁable ﬁelds of the TFTP /BootP Services window: The IP Address ﬁeld shows the IP Address of the CyberSWITCH or HSIM being IP Address — upgraded. Community — The Community ﬁeld allows you to enter the password of your CyberSWITCH or HSIM.
Page 161 QuickSET - Pull-Down Menus Figure 159 Compression and Congestion Window The Compression and Congestion window shows the type of compression employed (Hardware or Software Compression) in the window’s title bar. The Compression and Congestion window lets you to enable data compression on each interface. Data compression reduces the size of the data being sent on a WAN link, effectively extending the link bandwidth.
Page 162 Configuration with QuickSET Figure 160 Modify Compression and Congestion Window The deﬁnitions of the ﬁelds in the Compression and Congestion window are listed below: Interface # - Alias — Displays the available, pre-conﬁgured interface numbers and the alias names assigned to them. Compression —...
Page 163: Set Device Time And Date
QuickSET - Pull-Down Menus Set Device Time and Date The Set Device Time and Date window shown in Figure 161, displays when you click on the Runtime Conﬁguration item in the menu bar, and click on Set Device Time and Date. Figure 161 Set Device Time and Date Window Enter the new time and date in the respective data ﬁelds, and click the Update button to update the device date and time.
Page 164 Configuration with QuickSET QuickSET Configuration Guide...
