USER'S GUIDE
dnet
Required parameter. The destination network number.
dnode
Required parameter. The destination node Id.
timeout
Optional parameter. The number of seconds to wait for a reply message. The valid range is
from 1 to 60 seconds. The default value is 10 seconds.
nnnn
Optional parameter. The data size to be included in the ping packet. The valid range for the
data size is 5 to 586 octets. The default value is 100 octets.
An example atalk ping command could read as follows:
atalk ping 1.3 30 /d200
which would send a ping to node number 3 or network number 1, with a timeout value of 30
seconds, and the data size would be 200 octets.
atalk port
This command will display AppleTalk port information. A sample output screen is shown
below:
Port 1
type: LAN
address: 20.20
flags: extended
default zone: zone1
lan port: 1
Port 2
type: WAN
address: 30.30
flags: extended
default zone: zone1
Port 3
type: WAN UNNUMBERED state: UP
address: 20.20 (borrowed)
remote device: MAC4
The fields in this display are defined as follows:
type
The port type. Possible types are LAN, WAN, WAN UnNumbered.
Note that the WAN UnNumbered port information is not taken from the previously configured
AppleTalk Routing
configuration
state
The state of the port as it is in the process of coming up. Possible states include:
listen - The port is listening to see if any other routers are out on the network.
probing - The port is probing the network to see if its suggested AppleTalk address is
unique, or if it is already in use.
get_info - The port is verifying network information and obtaining the default zone.
526 CyberSWITCH
state: UP
network range 20-21
phase-2 soft-seed
physical address: 00409A001AB3
state: UP
network range 30-31
phase-2 soft-seed
port information, but is derived from the AppleTalk Routing
information.
static route
