USER'S GUIDE
For PPP, the ability to enable/disable outbound authentication (selection 3) is available.
However, it is generally not necessary to enable outbound authentications on a point-to-point
line. If the device is associated with a frame relay virtual circuit, and the PVC name is different
than the device name, then outbound authentication is required.
In addition, if you want to add user-level security to IP, AppleTalk and bridge devices, you
may also enable User Level Authentication. This requires the user that initiates a connection
between the remote device and the CyberSWITCH to be authenticated at the user level as well.
Refer to
Device and User Level Security
Note:
Do not enable User Level Authentication for terminal server devices which connect
through the digital modem.
Note:
The CSX1200, CSX1000, and CSX150 no longer connect to devices which use the RFC
1294 protocol to define their datalink headers. For these particular products only,
disregard (i.e., do not select) the IP Host (RFC 1294) menu option on the Device
Authentication Menu.
9.
To enter any needed IP information for your device, select IP from the Device Table Menu. The
following screen will be displayed:
Device IP Menu: (device = "DAN")
1) IP Address
2) IP Routing
3) Make calls for IP data
4) IP Input Filter
5) IP Output Filter
Select function from above or <RET> for previous menu:
If your device requires an IP address, enter it now. Options are:
•
none
•
0.0.0.0
•
IP address #
Enable or disable IP routing for this device.
If you want dial-out capabilities to this device, enable Make calls for IP data.
If you want to apply a predefined forwarding filter to this device, specify the filter name here.
Refer to
Forwarding Filters
10. To enter any needed IPX information for your device, select IPX from the Device Table Menu.
The following screen will be displayed:
Device IPX Menu: (device = "DAN")
1) IPX Routing
2) Make calls for IPX data DISABLED
3) IPXWAN Protocol
4) IPX Routing Protocol
5) Spoofing Options
Select function from above or <RET> for previous menu:
160
CyberSWITCH
for details.
for Direct Host or WAN links that plan to use dynamic address allocation
for unnumbered WAN links
for traditional numbered WAN links
for more information.
DISABLED
DISABLED
NONE
NONE
ENABLED
ENABLED
NONE
NONE
