C
ONFIGURING
O
VERVIEW
The AppleTalk routing feature allows the CyberSWITCH to efficiently route AppleTalk data as
opposed to bridging all data relating to the protocol. With the addition of the AppleTalk Remote
LAN feature, the CyberSWITCH can be configured to be a router, bridge or a mix of both when
handling AppleTalk traffic.
By default, AppleTalk routing is disabled when you first install your system software. To configure
the AppleTalk routing feature:
• enable AppleTalk routing
• configure AppleTalk port information
• configure AppleTalk static routes (optional)
• configure AppleTalk capacities
• enable/disable the AppleTalk isolated mode (optional)
A T R
PPLE ALK OUTING
E A T
NABLING PPLE ALK
U CFGEDIT
SING
1. AppleTalk routing is disabled by default. To perform any AppleTalk routing configuration,
you must first enable the feature. Select AppleTalk Routing from the Options menu.
2. Follow the onscreen instructions to enable AppleTalk Routing. The following menu will then
be displayed:
AppleTalk Configuration Menu:
1) AppleTalk Routing (Enable/Disable)
2) AppleTalk Ports
3) AppleTalk Static Routes
4) AppleTalk Capacities
5) Isolated Mode (Enable/Disable)
Select function from above or <RET> for previous menu:
Note: AppleTalk routing can not be enabled unless hardware filtering is disabled.
U M M C
SING ANAGE ODE
atalk
Displays the current AppleTalk Routing configuration.
A T
PPLE ALK
O
PTION
R
OUTING
OMMANDS
R
OUTING
