If you select PVC, the list of available PVCs are displayed. The LCN of the selected PVC and
the X.25 Access Name are stored in the Device Table to bind the device to a particular virtual

circuit configuration:

Select the type of the Virtual Circuit
1) Permanent Virtual Circuit (PVC)
2) Switched Virtual Circuit (SVC)
Current Permanent Virtual Circuits defined for X.25 Access #1, 'VMAX25':
id Type LCN Protocol
-- ---- ---- --------
1 PVC 1 RFC877
2 PVC 2 RFC877
Id of Virtual Circuit to associate with device "vma",
or <RET> to cancel?
If you select SVC, you must enter the X.121 address of the remote DTE. You need the remote
DTE address to make the X.25 call to the proper remote device.
Select the type of the Virtual Circuit
1) Permanent Virtual Circuit (PVC)
2) Switched Virtual Circuit (SVC)
Enter the X.121 Address of the Remote DTE
or press <RET> to cancel? 9987654321
8. Enter the authentication information needed. To begin entering the information, select
Authentication from the Device Table Menu. The following menu will then be displayed:
Device Authentication Menu: (device = "DAN")
PPP:
1) PAP Password
2) CHAP Secret
3) Outbound Authentication
4) User Level Authentication
IP Host (RFC 1294):
5) IP Host Id
HDLC Bridge:
6) Bridge Ethernet Address
7) Bridge Password
ISDN:
8) Calling Line Id(s)
Select function from above or <RET> for previous menu:
Provide the necessary device authentication information for your selected Line Protocol. (Refer
to On-node Device Database Security Requirements
specify a CHAP secret. Or, for an HDLC device, enter a Bridge Ethernet Address.
[default 2]: 1
1
[default 2]: 2
""
""
ENABLED
DISABLED
""
""
""
""
C D
ONFIGURING EVICE
On-node Device Entries
for details). For example, for a PPP device,
