USER'S GUIDE
IP Routing with IP Host Devices (RFC1294)
To allow an IP Host device to connect to the CyberSWITCH, you must have IP Routing and IP Host
Security enabled. For each IP Host device using this type of connection, you may need to enter the
device's IP address, IP Host Id, and Calling Line Id.
The following table identifies the configuration requirements for possible security options for IP
Host devices.
Security Mode Configuration
Calling Line Id
Disabled
Enabled
IP Routing with PPP IP Devices (Using IPCP)
To allow a PPP IP device to connect to the CyberSWITCH, you must have IP routing enabled. For
each PPP IP Device using this type of connection, you may need to enter the device's IP address, a
PAP Password or a CHAP Secret, and Calling Line Id.
The following table identifies the configuration requirements for possible security options for PPP
IP Devices.
Security Mode Configuration
Calling Line Id
Disabled
Enabled
Enabled
*Required: An IP address is required if the remote device does not support IP address negotiation.
When the remote device does support IP address negotiation, an IP address is not required.
Note: If CHAP Security is enabled, and Outbound Authentication has not been disabled, a CHAP
Secret must be entered for both the remote device and for the CyberSWITCH. Refer to
System Information
Authentication has been disabled, a CHAP Secret is not required for the remote device.
172 CyberSWITCH
IP Host Id Calling Line Id
Enabled Not Requested
Enabled Optional per
device entry
PAP or CHAP Calling Line Id
Security
Enabled Not Requested
Enabled Optional per
device entry
Disabled Required
for information regarding the System Secret. If Outbound
On-node Device Table Configuration Data
IP Host Id
Required
Required
On-node Device Table Configuration Data
PAP Password
or
CHAP Secret
Required
Optional
Optional
IP Address
Required
Required
IP Address
*Required
*Required
Optional
