R LAN D
EMOTE EVICES
Remote LAN devices are configured in a slightly different way than WAN devices. Since the
remote device is a bridge and not an IPX router, the IPX options for Remote LAN devices are
configured under the bridge-level options, as follows:
U CFGEDIT
SING
1. Select Security from the main menu.
2. Select Device Level Databases from the security menu.
3. Select On-node Device Entries from the device level databases menu.
4. Press 1 to add a device.
5. Enter the device's name and press <RET>. You should provide
information first.
6. Select Bridging from the Device Table Menu. A menu similar to the following will be displayed:
Device Bridging: (Device = "remote2")
1) IP (Sub)Network Number
2) Bridging
3) Make calls for bridge data
4) IPX Remote LAN Network Number NONE
5) IPX Spoofing Options
6) AppleTalk Network Number
Select function from above or <RET> for previous menu?
7. Enable Bridging and disable Make calls for bridge data.
8. Select IPX Remote LAN Network Number. Provide the external network number for the Remote
LAN interface if desired. The default value, NONE, means the remote IPX external number will
be the default IPX Remote LAN interface network number. Refer to
Note: The IPX Spoofing Options selection for Remote LAN devices is for a future release. Do not
try to configure at this time.
U M M C
SING ANAGE ODE OMMANDS
device add
Allows you to add a device entry to the Device List. You will be prompted for device
information, including IPX information.
device change
Allows you to change information for a specific device entry. This will allow you, for example,
to add IPX information to a previously configured device entry.
IPX-Specific Information for Devices
NONE
ENABLED
DISABLED
NONE
Workgroup Remote Access Switch
C
ONFIGURING
ISDN and Authentication
page 277.
IPX
295
