IP Configuration Menu:
1) IP Routing (Enable/Disable)
2)

IP Operating Mode

3) IP Interfaces
4) Static Routes
5) RIP (Enable/Disable)
6) IP Static ARP Table Entries.
7) Isolated mode (Enable/Disable)
8) Static Route Lookup via RADIUS (Enable/Disable)
9) Change IP Address Pool
10) IP filters
11) DHCP
Select function from above or <RET> for previous menu:
IP O C
PTION ONFIGURATION
IP O
PERATIONAL
You can enable or disable the Internet Protocol (IP) option. The default is disabled.
IP B I
ACKGROUND NFORMATION
When IP is enabled, the system acts as a router, routing IP datagrams based on IP address
information. The default configuration is IP disabled.
Note: If the bridge and the IP options are enabled, the CyberSWITCH will act as a brouter. A
brouter operates as a router for protocols it can route, and operates as a bridge for protocols
it cannot route.
IP O M
PERATING ODE
The operating mode may be either host or router. The router operating mode is the default. The IP
host mode (which allows you to use IP applications, such as Telnet and SNMP, on a bridged
network) is a selectable option.
The Simple Remote Bridging chapter of the Examples Guide provides an example of a simple bridged
network that uses the IP host operating mode for the purpose of easy administrative access.
C IP O
ONFIGURING THE
U CFGEDIT
SING
1. Select IP Operating Mode from the IP configuration menu.
2. Select either the IP router or IP host operating mode.
a. If you select IP router, the following menu is displayed:
E
LEMENTS
S
TATUS
M
PERATING ODE
C
ONFIGURING
Workgroup Remote Access Switch
B IP R
ASIC OUTING
IP Operating Mode
103
