USER'S GUIDE
Restricted Mode Bridge Filters
1.
SOURCE unicast-address FORWARD <distribution list>
This filter allows you to stipulate access privileges of a given device. When the specified unicast
address appears in the source address field of a MAC frame, the frame will be forwarded as
specified in the distribution list. In this manner, you can specify remote sites and LANs for
connection
2.
SOURCE unicast-address CONNECT < distribution list >
This filter allows you to stipulate access privileges of a given device. When the specified unicast
address appears in the source address field of a MAC frame, the frame will be connected and
forwarded as specified in the distribution list. In this manner, you can specify remote sites and
LANs for connection.
3.
DESTINATION MAC-address FORWARD <distribution list>
This filter allows you to forward MAC frames addressed to the specified MAC address. When
the specified MAC address appears in the destination address field of the MAC frame, the
frame will be forwarded as specified in the distribution list.
4.
DESTINATION MAC-address CONNECT< distribution list >
This filter allows you to connect MAC frames addressed to the specified MAC address. When
the specified MAC address appears in the destination address field of the MAC frame, the
frame will be connected and forwarded as specified in the distribution list.
230
CyberSWITCH
Restricted Mode
Type of Filter available
SOURCE
SOURCE
DESTINATION
DESTINATION
PROTOCOL
PROTOCOL
PACKET
PACKET
PACKET
Forwarding Action
FORWARD
CONNECT
FORWARD
CONNECT
FORWARD
CONNECT
FORWARD
DISCARD
CONNECT
