USER'S GUIDE
Banyan Vines Packet Detail Screen
Packet Number
0021
Destination Address
FFFFFFFFFFFF
EtherNet Type is 0BAD,
Check Sum
D75D
Transport Control
0
Dest Network Dest SubNet
FFFFFFFF
Packet Type
Query
IP Datagram Detail Screen
Packet Number
0009
Destination Address
001.001.001.001
45 00 1C 00 01 00 00 00 40 01 76 DD 01 01 01 01
01 01 01 01 08 00 C3 ED 34 12 00 00
While the "pkt display" is displayed on your monitor, you can display the following help
screen by entering "?":
ESC - Exit Menu
'u' - Previous Menu
'd' - Next Menu
'h' - Top of Packet List
'e' - End of Packet List
Enter - Display Packet Details
't' - Time Menu
'm' - Marks Packet as Start Time
Cursor- to select an entry
The time menu that is displayed when "t" is entered will enable you to toggle the time
increment to be in either Sec (seconds), mSec (milliseconds), or tSec (deciseconds).
When the packet marking option is used, all packet times will be displayed relative to that
marked packet. To mark a packet, use the arrow keys to move the cursor to the selected packet
number, then press "m" The time for that packet will be set to 0. All packets received before that
packet will have negative time values. All packets received after that marked packet will have
progressively higher positive time values.
548 CyberSWITCH
Received at Time
0000022190 mSEC
Source Address
02608C9BED38
VINES IP
Packet Length
0x001A
Hop Count
0
Source Network Source SubNet
FFFF 00000000
Network Number
126697007
Hit Escape to EXIT Packet Details
Received at Time
0000003190 mSEC
Source Address
001.001.001.001
Hit Escape to EXIT Packet Details
Hit any key to exit Help
(Bridged Packet)
Packet Length
0060
Protocol Type
04, ARP
0x0000
Subnetwork Number
0x9183
(Routed Datagram)
Packet Length
0028
E.......@.v.....
........4...
