Cabletron Systems SmartSwitch 2H22 Supplemental Manual

Local management supplement
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SmartSwitch Series
2E42, 2E43, 2E48, 2E49, 2H22,
2H23, 2H28, 2H33 and 2M46
Local Management Supplement
9032971-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartSwitch 2H22 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cabletron Systems SmartSwitch 2H22

Summary of Contents for Cabletron Systems SmartSwitch 2H22

  • Page 1 SmartSwitch Series 2E42, 2E43, 2E48, 2E49, 2H22, 2H23, 2H28, 2H33 and 2M46 Local Management Supplement 9032971-01...
  • Page 3 NOTICE Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.

  • Page 4: Program License Agreement

    BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (“Program”) in the package.
  • Page 5 If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...
  • Page 6 BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems Sales and Service, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (“Program”) in the package.
  • Page 7 If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...
  • Page 8 BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Cabletron Systems Limited (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (“Program”) in the package.
  • Page 9 If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,...

  • Page 10: Declaration Of Conformity

    ___________________________________ Title Rochester, NH, USA ___________________________________ Location viii 89/336/EEC 73/23/EEC Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr. J. Solari Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England...

  • Page 11: Table Of Contents

    1.2.2 Screen Format ... 1-5 Device Configuration Menu Screen... 1-6 System Resources Information Screen ... 1-8 1.4.1 Resetting the Reset Peak Switch Utilization ... 1-9 FLASH Download Configuration Screen ... 1-10 1.5.1 Image File Download Using TFTP ... 1-12 1.5.2 Image File Download Using Runtime ...
  • Page 12 1.20 Priority/Multicast Configuration Menu Screen ...1-50 1.21 Port Priority Configuration Screen ...1-52 1.21.1 Setting Switch Port Priority Port-by-Port ...1-53 1.21.2 Setting Switch Port Priority on All Ports ...1-53 1.22 Advanced Port Priority Configuration Screen ...1-54 1.22.1 Setting the TX Mapping Queues ...1-57 1.22.2 Setting the TX Regeneration Priorities ...1-57...
  • Page 13 GARP Multicast Registration Protocol (GMRP)... 4-3 GARP Operation Status Screen ... 4-4 4.3.1 Setting a Port to Operate in GMRP or GVRP ... 4-6 4.3.2 Setting All Ports on the Switch... 4-6 GMRP Configuration Screen ... 4-7 4.4.1 Setting a Mode, Port-by-Port ... 4-8 4.4.2 Setting a Mode for All Ports ...

  • Page 15: Figures

    VLAN Redirect Configuration Screen... 1-32 1-14 Broadcast Suppression Configuration Screen ... 1-35 1-15 802.1 Configuration Menu Screen... 1-38 1-16 Switch Configuration Screen ... 1-40 1-17 802.1Q VLAN Screen Hierarchy ... 1-43 1-18 802.1Q VLAN Configuration Menu Screen ... 1-44 1-19 IGMP/VLAN Configuration Screen ...
  • Page 16 Table User’s Guides Affected by Revisions...1-1 TX Queue Mapping Default Values ...1-55 TX Priority Regeneration Default Values ...1-56 ENET/Repeater Port Relationship ...2-6 CONN/Repeater Port Relationship ...3-3 CONN/Network Organization...3-4 CONN/Repeater Port Relationship ...3-8 CONN/Repeater Port Relationship ...3-11 CONN/Network Organization...3-12 TABLES Page Insert BookTitle...

  • Page 17: Chapter 1 Changes To Local Management Screens

    Table 1-1 User’s Guides Affected by Revisions Title 802.1Q VLAN User’s Guide 2E42-27/2E42-27R/2E43-27/2E43-27R User’s Guide 2E43-51/2E43-51R User’s Guide 2E48-27R/2E49-27R User’s Guide 2H22-08R User’s Guide 2H23-50R/2H33-37R User’s Guide 2H28-08R User’s Guide 2M46-04R/2M46-04RDC User’s Guide This document applies to several SmartSwitch models. Unless NOTE otherwise noted, the term SmartSwitch is used in the following text instead of a particular model number.

  • Page 18: Accessing Local Management

    802.1D Switching (traditional switching) • 802.1Q Switching (802.1Q port based VLANs) • SecureFast VLAN (Cabletron Systems SecureFast switching). A separate image is required for this operation. Refer to the Release Notes shipped with the product to verify NOTE which screens are supported in each of the available switching modes.
  • Page 19 Figure 1-1 802.1D Switching Mode, LM Screen Hierarchy Local Management Supplement Accessing Local Management Ethernet Full Duplex Configuration High Speed Interface Configuration * SmartTrunk Configuration Switch Configuration Port Redirect Configuration/ Redirect Configuration Menu Switch Statistics Interface Statistics Broadcast Suppression RMON Statistics Configuration ** Repeater Statistics...
  • Page 20 * Refer to the SmartTrunk User's Guide for the screen hierarchy. ** This screen is only available on repeater devices (2E43-51, 2E43-51R, 2H23-50R, and 2H33-37R). Indicates the part of the hierarchy that changed. Figure 1-2 802.1Q Switching Mode, LM Screen Hierarchy Switch Configuration 802.1Q VLAN Configuration Menu Device/VLAN Configuration...

  • Page 21: Screen Format

    1.2.2 Screen Format Since the top part of the screen contains the same type of information (the name of the screen, the SmartSwitch model number, the firmware revision, and the BOOT PROM revision), it is not shown in the following descriptions of the screens.

  • Page 22: Device Configuration Menu Screen

    Local Management screens that allow you to configure and monitor operating parameters, modify SNMP community names, set SNMP traps, configure switch parameters and configure ports. To access the Device Configuration Menu screen from the Device Menu screen, use the arrow keys to highlight the DEVICE CONFIGURATION menu item and press ENTER.

  • Page 23: Snmp Traps Configuration

    (FLASH memory, DRAM and NVRAM) in the device and the unused portion of each memory; and displays the current CPU (switch) utilization and the peak switch utilization. For details, refer to FLASH DOWNLOAD CONFIGURATION Used to force the SmartSwitch to download a new image file from a TFTP...

  • Page 24: System Resources Information Screen

    FLASH memory, DRAM, and NVRAM that is installed and how much of that memory is available. This screen is used to monitor the current switch utilization and the peak switch utilization. To access the System Resources Information screen from the Device Configuration Menu screen, use the arrow keys to highlight the SYSTEM...

  • Page 25: Resetting The Reset Peak Switch Utilization

    Shows the peak percentage of device switching capacity used, since the last reset. Reset Peak Switch Utilization (Toggle) Used to reset the Peak Switch Utilization field. The switch may be set to either YES or NO as described in Switch Utilization field to the current system utilization.

  • Page 26: Flash Download Configuration Screen

    Chapter 1: Changes to Local Management Screens FLASH DOWNLOAD CONFIGURATION SCREEN The Flash Download Configuration screen, shown in to download a new image file from a TFTP server to Flash memory. The user may also force the download of an image by changing NOTE the position of dipswitch 6 located inside the device.
  • Page 27 The following briefly defines each field of the Flash Download Configuration screen: Download Method (Selectable) This field steps between TFTP, RUNTIME and BOOTP. If set for BOOTP, the device sends out a BootP request to determine the IP address of the TFTP server and the filename of the image to be downloaded. If set for TFTP or RUNTIME, the SmartSwitch device attempts a TFTP download based on the IP address and filename entered in the fields at the bottom of the Flash Download Configuration screen.

  • Page 28: Image File Download Using Tftp

    Chapter 1: Changes to Local Management Screens Download Server IP (Selectable) The IP address of the TFTP server to be used for the FLASH download is entered in this field. Download File Name (Selectable) The complete TFTP server path and file name of the new image is entered in this field.

  • Page 29: Image File Download Using Runtime

    1.5.2 Image File Download Using Runtime Set the SmartSwitch device to download to FLASH using RUNTIME as follows: Use the arrow keys to highlight the Download Method field. Use the SPACE bar to step to RUNTIME. Use the arrow keys to highlight the Reboot After Download field. Use the SPACE bar to select either YES or NO.

  • Page 30: Image File Download Using Bootp

    Chapter 1: Changes to Local Management Screens 1.5.3 Image File Download Using BootP Set the SmartSwitch device to download to FLASH using BootP as follows: Use the arrow keys to highlight the Download Method field. Use the SPACE bar to select BOOTP. Use the arrow keys to highlight the TFTP Gateway IP Addr field.
  • Page 31 1.8. SMARTTRUNK CONFIGURATION Used to logically group interfaces together to create a greater bandwidth uplink. Refer to the Cabletron Systems SmartTrunk User’s Guide for information about how to access and use the SmartTrunk screens. Local Management Supplement Port Configuration Menu Screen...

  • Page 32: Ethernet Full Duplex Configuration Screen

    Chapter 1: Changes to Local Management Screens PORT REDIRECT CONFIGURATION Used to access the Redirect Configuration Menu screen, which provides access to the Port Redirect Configuration and VLAN Redirect Configuration screens. For details, refer to BROADCAST SUPPRESSION CONFIGURATION Used to set a desired limit of received broadcast frames that are forwarded out other interfaces.
  • Page 33 FULL DUPLEX – Depending on the SmartSwitch, the port transmits and receives data simultaneously at 10 or 100 Mbps, thus enabling the port to effectively switch at 20 or 200 Mbps. To set Ethernet ports for Full Duplex operation, refer to Local Management Supplement Ethernet Full Duplex Configuration Screen...

  • Page 34: Setting The Operational Mode

    • ENABLED – The port is turned on administratively. • DISABLED – The port is turned off administratively. Enabling or disabling ports from the Switch Configuration NOTE screen is described in SET ALL PORTS (Toggle) All front panel ports can be set at once to either STANDARD or FULL DUPLEX from this field.

  • Page 35: High Speed Interface Configuration Menu Screen

    High Speed Interface Configuration Menu Screen To set the Operational Mode for individual ports, proceed as follows: Use the arrow keys to highlight the Operation Mode field adjacent to the number of the port(s) that you plan to change. The Operation Mode for the first 12 ports can be changed on NOTE the first screen.
  • Page 36 Chapter 1: Changes to Local Management Screens To access the High Speed Interface Configuration Menu screen from the Port Configuration Menu screen, use the arrow keys to highlight the HIGH SPEED INTERFACE CONFIGURATION menu item and press ENTER. The High Speed Interface Configuration Menu screen, Figure 1-9, displays.

  • Page 37: High Speed Interface Configuration Screen

    HIGH SPEED INTERFACE CONFIGURATION SCREEN The High Speed Interface Configuration screen, NOTE applies only to installed optional Fast Ethernet Interface Modules. This screen supports the FE-100TX, FE-100FX, FE-100F3, and FE-100LH Fast Ethernet Interface Modules that operate at 100 Mbps. The High Speed Interface Configuration screen displays the types of installed Fast Ethernet Interface Modules, their current operating mode, and indicates if the ports are linked.
  • Page 38 Chapter 1: Changes to Local Management Screens The following briefly explains each field of the High Speed Interface Configuration screen. Port Type (Read-only) Displays the type of interface (FE-100FX, FE-100TX, FE-100F3, FE-100LH, or Unknown) installed. FE-100TX interface installed in one optional port slot and no interface indicated by Unknown in another optional port slot.

  • Page 39: Configuring An Fe-100Fx Or Fe-100F3

    In normal operation, the port with an FE-100TX installed NOTE automatically establishes a link with the device at the other end of the segment without requiring user setup. However, Local Management provides the user with the option of manually configuring that port. If an FE-100TX is installed, the field steps to Auto-Negotiation, 10Base-T, 10Base-TFD (full duplex), 100Base-TX, and 100Base-TXFD (full duplex).

  • Page 40: Setting The Fe-100Fx Or Fe-100F3 Operational Mode

    Chapter 1: Changes to Local Management Screens 1.9.2 Setting the FE-100FX or FE-100F3 Operational Mode Use this field to set the active technology. This field toggles between 100Base-FX and 100Base-FXFD (full duplex). To set the active technology through Local Management, proceed as follows: Use the arrow keys to highlight the Desired Operational Mode field.

  • Page 41: Setting The Fe-100Tx Advertised Ability

    Use the arrow keys to highlight the SAVE command. Press ENTER. The message “SAVED OK” displays and Local Management saves the changes to memory. The selected mode is displayed in both the Desired Operational Mode field and the Current Operational Mode field.

  • Page 42: Redirect Configuration Menu Screen

    For details, refer to Section 1.11. VLAN REDIRECT CONFIGURATION The VLAN Redirect Configuration screen is used to configure the device to direct traffic from a VLAN to a particular switch port. For details, refer Section 1.12. 1-26 (Figure...

  • Page 43: Port Redirect Configuration Screen

    1.11 PORT REDIRECT CONFIGURATION SCREEN The Port Redirect Configuration screen, redirect frames from one source port to one destination port. Frames received on the source port can be redirected and transmitted in the frame format in which they are received (normal), or they can be redirected with a VLAN Tag (TAGGED) or without a VLAN Tag (UNTAGGED).
  • Page 44 Chapter 1: Changes to Local Management Screens To access the Port Redirect Configuration screen from the Redirect Configuration Menu screen, use the arrow keys to highlight the PORT REDIRECT CONFIGURATION menu item and press ENTER. The Port Redirect Configuration screen displays. Source Port -------------------- Source Port...
  • Page 45 Frame Format (Read-Only) Displays the current frame format setting: NORMAL, TAGGED or UNTAGGED The default is NORMAL. • NORMAL – Frames are redirected in the format that they were received or transmitted on the source port. • TAGGED – Frames are transmitted on the destination port with a VLAN tag inserted according to the frame classification.

  • Page 46: Changing Source And Destination Ports

    Chapter 1: Changes to Local Management Screens 1.11.1 Changing Source and Destination Ports To add or delete source port and destination port entries and set the Frame Format and Redirect Errors functions, proceed as follows: Use the arrow keys to highlight the Source Port field near the bottom of the screen.

  • Page 47: Vlan Redirect Configuration Screen

    If more than one port is being redirected, repeat steps 1 through 10 for each additional setting. Then go to step 11 to save all the new settings at once. If an entry is to be changed, delete the entry, save the screen, then recreate the entry with its new settings.
  • Page 48 Chapter 1: Changes to Local Management Screens To access the VLAN Redirect Configuration screen from the Redirect Configuration Menu screen, use the arrow keys to highlight the VLAN REDIRECT CONFIGURATION menu item and press ENTER. The VLAN Redirect Configuration screen displays. Source VLAN --------------------- Source VLAN...
  • Page 49 Frame Format (Read-Only) Displays the current frame format setting: RECEIVED, TAGGED or UNTAGGED. The default is RECEIVED. • RECEIVED – Frames are redirected in the format that they were received by the SmartSwitch device. • TAGGED – Frames are transmitted on the destination port with a VLAN tag inserted according to the frame classification of the receiving port.

  • Page 50: Changing Source Vlan And Destination Ports

    Chapter 1: Changes to Local Management Screens 1.12.1 Changing Source VLAN and Destination Ports To add or delete source VLAN and destination port entries and set the Frame Format, proceed as follows: Use the arrow keys to highlight the Source VLAN field near the bottom of the screen.

  • Page 51: Broadcast Suppression Configuration Screen

    Use the arrow keys to highlight SAVE at the bottom of the screen. Press ENTER. The message “SAVED OK” displays. This saves the new settings and updates the Source Port and Destination Port read-only fields. 1.13 BROADCAST SUPPRESSION CONFIGURATION SCREEN The Broadcast Suppression Configuration screen, the user to set a desired limit of receive broadcast frames that are switched out to the other ports.

  • Page 52: Setting The Threshold

    Chapter 1: Changes to Local Management Screens The following explains each field of the Broadcast Suppression screen: PORT # (Read-Only) Identifies the number of the port. Total RX (Read-Only) Displays the total number of broadcast frames received. Peak Rate (Read-Only) Displays the highest number of broadcast frames received in a one-second interval.

  • Page 53: Resetting The Reset Peak

    [13 - 24] (Navigation Key) When the Switch Configuration screen displays, the current screen settings are displayed for the first 12 ports. This field is used to step to the next screen for the same type of information for the next twelve ports, if available.

  • Page 54: Configuration Menu Screen

    Figure 1-15 802.1 Configuration Menu Screen The following briefly describes each screen that is accessible from the 802.1 Configuration Menu screen. SWITCH CONFIGURATION Provides the basic setup options for customizing the operation of a switch device in the network. For details, refer to 1-38 Figure...

  • Page 55: Priority Configuration

    Systems 802.1Q VLAN User’s Guide. GARP OPERATION STATUS Used to enable/disable GVRP and GMRP on the switch and set each port to operate as a GVRP- or GMRP-aware port so it can send/receive frames from other GVRP- or GMRP-aware devices. GVRP and GMRP enables the switch to dynamically create VLANs and Multicast Registration across a switched network.

  • Page 56: Switch Configuration Screen

    Type of STA (Toggle) Allows the user to set the method that the switches use to decide which switch is the controlling (Root) switch when two or more switches exist in parallel (Spanning Tree Algorithm). Valid entries include IEEE, DEC, and NONE.
  • Page 57 Age Time (Modifiable) Allows the user to set the amount of time (in seconds) that the SmartSwitch keeps an address in its switch table before discarding it. An address is automatically discarded when a valid frame is not received from that address within the time specified in the Age Time field. To change the Age Time field from the default value of 300 seconds, refer to...

  • Page 58: Setting The Sta

    The Spanning Tree Algorithm (STA) setting allows the user to set the method that the switches use to decide which is the controller (Root) switch when two or more switches are in parallel. The available selections are IEEE, DEC, and NONE.

  • Page 59: Setting (Enabling Or Disabling) The Port Status

    A switch supporting 802.1Q VLANs provides the VLAN Configuration screens as a standard part of its Local Management hierarchy when the switch is configured to operate in 802.1Q Mode. The hierarchy of the Local Management screens pertaining to 802.1Q VLAN configuration is...

  • Page 60: Q Vlan Configuration Menu Screen

    Used to view, add, name, enable, or disable VLANs within the device, and also associate the VLANs to a Filter Database ID (FID). It also enables the user to configure attributes that apply to the entire switch and/or VLANs. Refer to your SmartSwitch device user’s guide for additional information.

  • Page 61: Protocol Vlan Configuration

    IGMP/VLAN Configuration Screen PORT FILTERING CONFIGURATION Used to set the switch to filter out inbound frames to prevent them from being forwarded by the switch out a particular port. This screen also lists the VLANs that have frames eligible to be transmitted out that port. Refer to your SmartSwitch device user’s guide for additional information.
  • Page 62 Chapter 1: Changes to Local Management Screens IGMP is enabled or disabled by VLAN, not port by port. Certain versions of firmware will not allow the switch to be a NOTE querier. Please check your release notes for further information. Refer to RFC 2236, Section 8, for more information on IGMP.
  • Page 63 IGMP. Query Interval (Modifiable) If the switch is the querier, the value in the Query Interval field indicates how often IGMP Host-Query frames are transmitted on the VLAN selected in the VLAN ID field. This value is also used in calculations for other timers.
  • Page 64 A reduced value results in reduced time to detect the loss of the last member of a group. The interval is in tenths of seconds. This value is not used if the switch is not the querier.

  • Page 65: Configuring Vlans For Igmp

    ENABLED and DISABLED will act only on the VLAN whose ID is in the VLAN ID field. The commands ENABLE ALL and DISABLE ALL act on all VLANs available to the switch. Default for new VLANS (Toggle) New VLANs can be set up by default to be either ENABLED or DISABLED.

  • Page 66: Priority/Multicast Configuration Menu Screen

    ENTER key to save the information in all the fields that were changed. The event message line will indicate “SAVED OK” and the screen can now be exited. To set up a VLAN, refer to the Cabletron Systems 802.1Q VLAN User’s Guide.

  • Page 67: Port Priority Configuration

    Figure 1-20 Priority/Multicast Configuration Menu Screen The Priority/Multicast Configuration Menu screen displays the following menu items: PORT PRIORITY CONFIGURATION Used to set the port default transmit priority (0 through 7) of each port for frames that are received without priority information in their tag header. For details, refer to Section ADVANCED PORT PRIORITY CONFIGURATION...

  • Page 68: Port Priority Configuration Screen

    ENTER. The Port Priority Configuration screen displays. Port # SAVE Figure 1-21 Port Priority Configuration Screen 1-52 Figure Priority Set All Switch Port's Priority PREVIOUS NEXT Local Management Supplement 1-21, is used to set the Port # Priority EXIT...

  • Page 69: Setting Switch Port Priority Port-By-Port

    1.21.2 Setting Switch Port Priority on All Ports To set the port priority on all ports, proceed as follows: Use the arrow keys to highlight the Set All Switch Port’s Priority field. Press the SPACE bar to select a priority from 0 through 7 (0 is the lowest priority).

  • Page 70: Advanced Port Priority Configuration Screen

    Chapter 1: Changes to Local Management Screens Use the arrow keys to highlight the SAVE command at the bottom of the screen. Press ENTER. The message “SAVED OK” displays and the setting is saved. 1.22 ADVANCED PORT PRIORITY CONFIGURATION SCREEN The Advanced Port Priority Configuration screen, set the Priority/Queue Mapping and Priority Regeneration for a particular port or change the default port priority.
  • Page 71 Priority/Queue Mapping ------------------------------- Priority Default Priority SAVE PREVIOUS Figure 1-22 Advanced Port Priority Configuration Screen The following describes each field of the Advanced Port Priority Configuration screen: Priority (Read-Only) Lists the eight priorities, 0 through 7. TX Queue (Toggle) Enables the frames with a certain priority to be mapped to transmit according to one of two TX queues (0 or 1) with 0 being the lowest transmit level.
  • Page 72 Chapter 1: Changes to Local Management Screens TX Priority (Selectable) Enables the frames with a certain RX priority to be changed to transmit according to a different TX priority (0 through 7). The following describes how the frames of learned traffic are handled. When a frame is received, it is checked to see if it has a priority.

  • Page 73: Setting The Tx Mapping Queues

    1.22.1 Setting the TX Mapping Queues To set the TX queue for frames with a particular priority, proceed as follows: Use the arrow keys to highlight the Port # field. Type in the number of the port to which the TX queue setting will be applied.

  • Page 74: Setting The Default Priority Of A Port

    Chapter 1: Changes to Local Management Screens Press the SPACE bar to step to the appropriate value, 0 through 7. The 0 selection is the lowest level TX priority value. If more than one TX priority is to be changed, repeat steps 4 and 5 until all the appropriate TX priority settings are changed.

  • Page 75: Chapter 2 Lm Security Screens For 2E43-51/2E43-51R Devices

    LM SECURITY SCREENS FOR 2E43-51/2E43-51R DEVICES The information in this chapter replaces the information about the Repeater Configuration Menu and Repeater Port Configuration screens provided in the 2E43-51/2E43-51R SmartSwitch 2100 User’s Guide. REPEATER CONFIGURATION MENU SCREEN The Repeater Configuration Menu screen, the Repeater Level Security Configuration, or Port Level Security Configuration screen.

  • Page 76: Repeater Level Security Configuration

    (LockOnNext), or lock on the source address of the last frame received (LockedOnAddr). When either of the last two options are set, the switch can be set to enable or disable the reception of frames and send or not send traps when an intruder is detected.
  • Page 77 Interface SAVE Figure 2-2 Repeater Level Security Configuration Screen The following section defines the fields on the Repeater Level Security Configuration screen. Interface (Read-Only) Indicates the interface connector (ENET 1 through 4) selected in the Interface field. Security State (Selectable) Used to set all ports on an interface connector to the same security state.

  • Page 78: Setting The Repeater Level Security

    With NoDisable set, the port is not turned off. • SendTrap/NoTrap – SendTrap causes the switch to send an SNMP trap when a port detects a security violation. With NoTrap set, no SNMP trap is sent.

  • Page 79: Port Level Security Configuration Screen

    To change the DisablePort setting to NoDisablePort, press the SPACE bar to toggle the setting. Use the arrow keys to highlight the SendTrap field. To change the SendTrap setting to NoTrap, press the SPACE bar to toggle the setting. To change the security on all interface ports on more than one connector, repeat proceed to step 8...
  • Page 80 Chapter 2: LM Security Screens for 2E43-51/2E43-51R Devices Port Security State [LockedOnAddr] [NonSecure] [LockedOnAddr] [LockOnNext] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] SAVE INTERFACE #: [1] Figure 2-3 Port Level Security Configuration Screen The following section defines the fields on the Port Level Security Configuration screen.
  • Page 81 With NoDisablePort set, the port is not turned off. • SendTrap/NoTrap – SendTrap causes the switch to send an SNMP trap when a port detects a security violation. With NoTrap set, no SNMP trap is sent.

  • Page 82: Setting The Port Level Security

    Chapter 2: LM Security Screens for 2E43-51/2E43-51R Devices INTERFACE # (Selectable) Used to select the front panel interface connector (ENET 1 to ENET 4) to which the port security settings will be applied. 2.3.1 Setting the Port Level Security To set the security for each repeater port on a connector, proceed as follows: Use the arrow keys to highlight the INTERFACE # field.
  • Page 83 Use the arrow keys to highlight the SAVE command. Press ENTER. The message “SAVED OK” displays and all ports of the connector are set to the selected operating mode. To change the security on a different interface connector, repeat through step 14 as needed.
  • Page 84 Chapter 2: LM Security Screens for 2E43-51/2E43-51R Devices 2-10 Local Management Supplement...

  • Page 85: Chapter 3 Lm Security Screens For 2H23-50R/2H33-37R Devices

    LM SECURITY SCREENS FOR 2H23-50R/2H33-37R DEVICES The information in this chapter replaces the information about the Repeater Configuration Menu and Repeater Port Configuration screens provided in the 2H23-50R/2H33-37R SmartSwitch 2100 User’s Guide. REPEATER CONFIGURATION MENU SCREEN The Repeater Configuration Menu screen, the Repeater Port Configuration, Module Level Security Configuration, or Port Level Security Configuration screen.

  • Page 86: Repeater Port Configuration Screen

    Chapter 3: LM Security Screens for 2H23-50R/2H33-37R Devices The following introduces each screen that is accessible from the Repeater Configuration Menu. REPEATER PORT CONFIGURATION Used to monitor the link status and current operating mode of each port on the 10-Mbps or 100-Mbps network of a front panel connector, and also turn each port on or off.
  • Page 87 PORT# NETWORK# LINK STAT. No Link No Link Link No Link No Link No Link No Link No Link No Link No Link No Link No Link SAVE SET ALL PORTS: [Auto-Neg] Figure 3-2 Repeater Port Configuration Screen The following are definitions for each field of the Repeater Port Configuration screen: PORT # (Read-only) Indicates the repeater port on the connector selected in the CONNECTOR...
  • Page 88 Chapter 3: LM Security Screens for 2H23-50R/2H33-37R Devices NETWORK # (Read-only) Indicates the network on the connector selected in the CONNECTOR field. Table 3-2 shows the association between the connector (CONN) and Networks on the device. Table 3-2 CONN/Network Organization 2H23-50R CONN 1 = Network 1, 10 Mbps Network 2, 100 Mbps...

  • Page 89: Setting The Port Operating Mode

    PORT STAT. (Toggle) Used to enable (turn on) or disable (turn off) the port. To enable or disable the port, refer to Section SET ALL PORTS (Selectable) Used to select operating mode for all the ports on the connector simultaneously. This field steps through the following selections: Auto-Neg., 10Base T, and 100Base-TX.

  • Page 90: Setting Operating Mode On All Repeater Ports

    Chapter 3: LM Security Screens for 2H23-50R/2H33-37R Devices Press ENTER to display the repeater port settings on that connector. Use the arrow keys to highlight the PORT STAT. field of the repeater port being enabled or disabled. Use the SPACE bar to toggle to the appropriate setting (Enable or Disable).

  • Page 91: Module Level Security Configuration

    (LockOnNext) or the source address of the last frame received (LockedOnAddr). When either of the last two options are set, the switch can be set to enable or disable the reception of frames and send or not send traps when an intruder is detected.
  • Page 92 Chapter 3: LM Security Screens for 2H23-50R/2H33-37R Devices The following section defines the fields on the Module Level Security Configuration screen. Connector (Read-Only) Indicates the connector. Refer to (CONN)/repeater port relationship on the device. Table 3-3 CONN/Repeater Port Relationship 2H23-50R CONN 1 = Repeater ports 1 –...

  • Page 93: Setting The Module Level Security

    With NoDisable set, the port is not turned off. • SendTrap/NoTrap – SendTrap causes the switch to send an SNMP trap when a port detects a security violation. With NoTrap set, no SNMP trap is sent.

  • Page 94: Port Level Security Configuration Screen

    Chapter 3: LM Security Screens for 2H23-50R/2H33-37R Devices Use the arrow keys to highlight the SendTrap field. To change the SendTrap setting to NoTrap, press the SPACE bar to toggle the setting. To change the security on more than one connector, repeat steps 1 through 6 for each connector.
  • Page 95 Security State Port Network [LockOnNext] [NonSecure] [LockedOnAddr] [DisablePort] [SendTrap] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] [NonSecure] SAVE CONNECTOR #: [1] Figure 3-4 Port Level Security Configuration Screen The screen will not refresh automatically. To check if the states NOTE have changed, such as from LockOnNext to LockedOnAddr, the screen must be exited (Return may be used) and...
  • Page 96 Chapter 3: LM Security Screens for 2H23-50R/2H33-37R Devices Network (Read-only) Indicates the network to which the port is currently attached. shows the association between the connector (CONN) and Network on the device. Table 3-5 CONN/Network Organization 2H23-50R CONN 1 = Network 1, 10 Mbps Network 2, 100 Mbps CONN 2 = Network 3, 10 Mbps Network 4, 100 Mbps...

  • Page 97: Setting The Port Level Security

    With NoDisable set, the port is not turned off. • SendTrap/NoTrap – SendTrap causes the switch to send an SNMP trap when a port detects a security violation. With NoTrap set, no SNMP trap is sent.
  • Page 98 Chapter 3: LM Security Screens for 2H23-50R/2H33-37R Devices Use the SPACE bar to step to the appropriate connector (CONN) number. Press ENTER to display the 12 repeater ports of the selected connector. Use the arrow keys to highlight the Security State field for the desired repeater port.

  • Page 99: Chapter 4 Generic Attribute Registration Protocol (Garp)

    GARP VLAN Registration Protocol (GVRP) The process of the forwarding decision and tagging frames is the same as for 802.1Q as described in the Cabletron Systems 802.1Q VLAN User’s Guide. However, the GVRP protocol frames will not have a tag even when transmitted out a 1Q Trunk Port.
  • Page 100 4-1, Switch 4, port 1 is registered as being a member of VLAN Blue and then declares this fact out all its ports (2 and 3) to Switch 1 and Switch 2. These two switches register this in the Port VLAN Lists of the ports (Switch 1, port 1 and Switch 2 Port 1) that received the frames with the information.

  • Page 101: Garp Multicast Registration Protocol (Gmrp)

    Configuring a VLAN on an 802.1Q switch creates a static GVRP entry. The entry will always remain registered and will not time out. However, dynamic entries will time-out and their registrations are removed from the member list if the end station A is removed. This ensures that if switches are disconnected, or if end stations are removed, the registered information remains accurate.

  • Page 102: Garp Operation Status Screen

    GARP OPERATION STATUS SCREEN The GARP Operation Status screen, the switch as GMRP- and GVRP-aware ports. The ports may be enabled one by one or all at the same time for GMRP and GVRP. To access the GARP Operation Status screen, use the arrow keys to highlight the GARP OPERATION STATUS menu item on the 802.1...
  • Page 103 To set all ports, refer to GMRP Protocol (Toggle) Enables or disables the GMRP Protocol on the switch. When set to Enable, all port settings are valid for GMRP, enabling those ports to send/receive frames to other GMRP-aware switches. Disable makes the port settings invalid.

  • Page 104: Setting A Port To Operate In Gmrp Or Gvrp

    4.3.2 Setting All Ports on the Switch All ports on the switch can be set at one time to one mode of operation using the Set All Ports field. To select the mode of operation using the Set All Ports field, proceed as...

  • Page 105: Gmrp Configuration Screen

    Press ENTER. Use the arrow keys to highlight the SAVE command at the bottom of the screen. Press ENTER. The message “SAVED OK” displays. GMRP CONFIGURATION SCREEN The GMRP Configuration screen, operation mode of each port. To access the GMRP Configuration screen, use the arrow keys to highlight the GMRP GROUP REGISTRATIONS menu item on the 802.1 Configuration Menu screen and press ENTER.

  • Page 106: Setting A Mode, Port-By-Port

    Chapter 4: Generic Attribute Registration Protocol (GARP) Mode (Selectable) Select one of the following four modes of operation: • Use GMRP Filter Unreg – Do not forward multicast addressed frames out this port that have an unregistered multicast address. • Forward All Groups –...

  • Page 107: Setting A Mode For All Ports

    4.4.2 Setting a Mode for All Ports The modes of operation are the same as the ones described in Section 4.4.1, except that all ports are affected. To set all the ports to operate in one mode, proceed as follows: Use the arrow keys to highlight the Set All Ports field.

  • Page 109: Chapter 5 Network Tools

    This chapter introduces the “cdp” command and shows how it affects the Network Tools Help screen. The cdp command is an addition to the built-in commands listed in your SmartSwitch user’s guide. NETWORK TOOLS The Network Tools function resides on the platform firmware and allows the user to access and manage network devices.

  • Page 110: Built-In Command

    Chapter 5: Network Tools Welcome to Network Tools -> help Commands Available to the Built in Commands: bridge netstat ping show traceroute telnet soft_reset atm_stp_state cdp SPECIAL: done, quit, or exit - Exit from the Network Tools. For help with a specific command, type 'help <command>'. ->...
  • Page 111 Description: Allows management of Cabletron Discovery Protocol (CDP) on this device. This protocol is used by SmartSwitch device to discover other neighboring network devices and establish the topology of the network fabric. This protocol can also be used by the SmartSwitch device to propagate specific information to neighboring network devices.The user may enable, disable, or see the current status of CDP.

  • Page 113: A.1 Igmp Overview

    IGMP OVERVIEW IGMP is a multicast protocol used by routers. This protocol is supported by Cabletron Systems SmartSwitches when operating in the 802.1Q mode to “snoop” the IGMP frames. The multicast information is gleaned from the IGMP frame and a filter is created to send the stream of data only to those end stations that request to receive it.

  • Page 114: Appendix A: About Igmp

    IGMP will run with GMRP, however, the IGMP does have higher priority than GMRP. • The switch does not act as the querier. A router is required for IGMP on the switch to function. • The switch will “snoop” on all incoming multicast addresses to detect query responses, as well as queries.
  • Page 115 There are many multicast routing protocols that the switch supports. These include the following: • PIM version 1 and 2 • CBT (core based trees) • MOSPF • DVMRP The routing protocols are detected as follows: • All the multicast routing protocols have a destination address of 01-00-5E.

  • Page 117: Index

    Numerics 802.1D switching mode hierarchy of 802.1Q switching mode hierarchy of Advanced Port Priority Configuration screen default priority 1-56 Port command 1-57 port# 1-56 priority 1-55 RX priority 1-55 TX priority 1-56 tx queue 1-55 Age time 1-41 Bridge Configuration screen state 1-41 Broadcast Suppression Configuration...
  • Page 118 Port Operating Mode (2Hxx) setting of 1-48 Port Priority Configuration screen 1-48 port # priority 1-48 set all switch port’s flow Port Redirect Configuration screen 1-48 destination port frame format (read only) 1-29, frame format (selectable) redirect errors 1-29, redirect errors (toggle)
  • Page 119 Repeater Configuration Menu screen Repeater Configuration Menu screen (2Exx) Repeater Configuration Menu screen (2Hxx) Repeater Level Security Configuration screen (2Exx) Switch Configuration screen System Resources Information screen 1-54 VLAN Redirect Configuration screen 1-35 Set a port to operate in GMRP or GVRP...
  • Page 120 STA 1-40 System Resources Information screen CPU type current switch utilization DRAM installed FLASH memory installed NVRAM installed peak switch utilization reset peak switch utilization Table formats Transmit queues mapping of 1-57 TX priorities regeneration off 1-57 Index-4...
