Position Error Counter

The position error counter is used to calculate the error between
the command position and the feedback position. It will add one
count when the HSL-4XMO outputs one pulse and subtracts one
count when the HSL-4XMO receives one pulse (from EA, EB). It is
useful in detecting step-loses (stalls) in situations of a stepping
motor when an encoder is applied.
Since the position error counter automatically calculates the differ-
ence between pulses outputted and pulses fed back, it is inevita-
ble to get an error if the motion ratio is not equal to "1."
To obtain a position error reading, use the function call
HSL_M_get_error_counter(). To reset the position error counter,
use the function call HSL_M_reset_error_counter(). The position
error counter will automatically clear to "0" after home move is
complete.
Relative Functions:
HSL_M_get_error_counter()
HSL_M_reset_error_counter():

General Purpose Counter

The general purpose counter is very versatile. It can be any of the
following:
1. Pulse output – as a command position counter
2. Pulse input – as a feedback position counter
3. Manual Pulse input – Default status.
4. Clock – an accurate timer (9.8 MHz)
The default setting of the general purpose counter is set to manual
pulse. (Refer to section 4.1.9 for a detailed explanation of manual
pulsing). To change the source type, use the function
HSL_M_set_general_counter(). To obtain the counter status, use
the function HSL_M_get_general_counter().
Relative Functions:
HSL_M_set_general_counter()
HSL_M_get_general_counter()
Operation Theory 67
