ALM Logic and Response mode: Select logic and response

modes

ALM

HSL_M_set_alm().

1. INP Logic and Enable/Disable selection: Select logic,

and Enable/ Disable the INP signal. The related function

call is HSL_M_set_inp()

2. ERC Logic and Active timing: Select the Logic and

Active timing of the ERC signal. The related function call

is HSL_M_set_erc().

3. EL Response mode: Select the response mode of the

EL signal. The related function call is HSL_M_set_el().

4. ORG Logic: Select the logic of the ORG signal. The

related function call is HSL_M_set_home_config().

5. EZ Logic: Select the logic of the EZ signal. The related

function call is HSL_M_set_home_config().

6. SD Configuration: Configure the SD signal. The related

function call is HSL_M_set_sd().

7. LTC Logic: Select the logic of the LTC signal. The related

function call is HSL_M_set_ltc_logic().

8. Buttons:

Next Axis: Change operating axis.

Save Config: Save current configuration to HSL-4XMO.ini.

Operate: Go to the operation menu, refer to section 5.3.4

Config Pulse : Go to the Pulse IO Configuration menu, refer

to section 5.3.3

Back: Return to the main menu.

Pulse IO Configuration Menu

In this menu, users can configure pulse input/output and move

ratio and INT factor.

Motion Creator in LinkMaster

signal.

The

function

call
