Digital Input
Sink or source type can be selected via ICOM
Switching capability: 10K Hz
Input voltage range:
Logic H: 14.4~24V
Logic L: 0~5V
Input resistor: 4.7K? @ 0.5W
Isolated voltage: 500 Vrms
Digital Output
Output type: Open-collector (PC3H7C)
Sink Current: 4 mA max.
Switching capability: 10 KHz @ 24V, load = 4.7 K?
Isolated voltage: 500 Vrms
General Purpose Output
Output type: NPN sinking type for –N module; PNP sourcing
type for –P module
Sink Current: 90 mA max.
Switching capability: 2 KHz @ 24V, load = 300 ?
Isolated voltage: 500 Vrms
General Specifications
Operating Temperature: 0
Storage Temperature: -20
Humidity: 0 % – 90 %, non-condensing
Power Consumption
5 Watts max. @ 24 Vin
Dimensions
163.5 mm (W) × 74.9 mm (D) × 52.7 mm (H)
