- Page 1 AVA-5500 AI-Enabled Video Analytics Platform User’s Manual Manual Rev.: March 31, 2020 Revision Date: 50-1Z294-2010 Part No: Leading EDGE COMPUTING...
- Page 2 Leading EDGE COMPUTING Revision History Revision Release Date Description of Change(s) 2019-09-09 Initial release SIM card slots moved to front panel; add optional 2020-03-31 4x isolated DIO; add AVA-5520 content Revision History...
-
Page 3: Preface
AVA-5500 Preface Copyright © 2020 ADLINK Technology Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer. - Page 4 Leading EDGE COMPUTING California Proposition 65 Warning WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene, cadmium, Tris(1,3-dichloro-2-propyl)phosphate (TDCPP), 1,4-Diox- ane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause...
-
Page 5: Table Of Contents
AVA-5500 Table of Contents Revision History..............ii Preface ..................iii List of Figures ................ ix List of Tables................xi 1 Introduction ................ 1 Overview................1 Features................2 Package Contents ............... 3 2 System Description............5 AVA-5500/5510 Specifications ..........5 DisplayPort Feature Support ..........8 Block Diagram .............. - Page 6 Leading EDGE COMPUTING Connections ............... 24 Starting Up the System ............26 4 Interfaces ................27 Pin Definitions ..............27 Status LEDs ............... 37 Power Button ..............38 Reset Button ..............38 5 BIOS Setup ................ 39 Introduction ................ 39 Entering BIOS Setup............
- Page 7 AVA-5500 Security Menu..............61 5.5.1 Secure Boot ..............61 Boot Menu ................. 62 Save & Exit Menu .............. 63 BIOS Beep Codes ............. 63 Important Safety Instructions ..........65 Getting Service..............67 Table of Contents...
- Page 8 Leading EDGE COMPUTING This page intentionally left blank. viii Table of Contents...
-
Page 9: List Of Figures
Figure 2-1: AVA-5500 Block Diagram ..........9 Figure 2-2: AVA-5500/5520 Dimensions.......... 10 Figure 2-3: AVA-5510 Dimensions........... 11 Figure 2-4: AVA-5500 Series Front Layout ........12 Figure 2-5: AVA-5500/5200 Rear I/O Layout ........13 Figure 2-6: AVA-5510 Rear I/O Layout ..........13... - Page 10 Leading EDGE COMPUTING This page intentionally left blank. List of Figures...
-
Page 11: List Of Tables
AVA-5500 List of Tables Table 2-1: AVA-5500/5510 Specifications ........5 Table 2-2: DisplayPort Feature Support ........... 8 Table 2-3: AVA-5500/5510 Power Consumption ......14 Table 2-4: AVA-5200 Power Consumption ........15 Table 4-1: GbE M12 A-code Pin Definition ........27 Table 4-2: GbE M12 X-code Pin Definition ........ - Page 12 Leading EDGE COMPUTING This page intentionally left blank. List of Tables...
-
Page 13: Introduction
AVA-5500 Introduction 1.1 Overview The AVA-5500 Series is a high performance fanless AI-Enabled Video Analytics Platform equipped with the 6th/7th Gen Intel® Core™ i7 Processor and integrated NVIDIA Quadro GPGPU mod- ule. This EN50155 certified AIoT Platform is not only ruggedized... -
Page 14: Features
Leading EDGE COMPUTING 1.2 Features 6th/7th Gen Intel® Core. i7 Processor Supports Type A and B MXM on PCI Express x16 for add-on GPU module EGX-MXM-P1000: 512 CUDA cores, 1.8 TFLOPS peak, 4GB GDDR5 memory EGX-MXM-P2000: 768 CUDA cores, 2.3 TFLOPS peak, 4GB GDDR5 memory EGX-MXM-P3000: 1280 CUDA cores, 3.9 TFLOPS peak, 6GB GDDR5 memory... -
Page 15: Package Contents
1.3 Package Contents Please check that your package contains the items below. If you discover damaged or missing items, please contact your vendor. AVA-5500 Series AI-Enabled Video Analytics Platform Wall-mount bracket Screw pack for wall-mounting and SSD drives DO NOT install or apply power to equipment that is damaged or if there is missing/incomplete equipment. - Page 16 Leading EDGE COMPUTING Mini PCIe Cellular Kit for Taiwan, China (P/N: 91-95247-400E) 1x Mini PCIe Cellular module (SIMCOM SIM7100C-PCIE, GSM/TD-SCDMA/CDMA/WCDMA/LTE/GNSS) 2x external antennas 2x internal RF cables Mini PCIe Cellular Kit for Europe (P/N: 91-95247-500E) 1x Mini PCIe Cellular module (SIMCOM SIM7100C-PCIE, GSM/TD-SCDMA/CDMA/WCDMA/LTE/GNSS) 2x external antennas 2x internal RF cables...
-
Page 17: System Description
AVA-5500 System Description 2.1 AVA-5500/5510 Specifications Model AVA-5500 AVA-5510 AVA-5520 System Core Intel® Core™ i7-6820EQ, 2.8GHz Processor Intel® Core™ i7-7820EQ, 3.0GHz Memory DDR4 2133 8GB by SODIMM, up to 32GB Graphics Outputs 2x DisplayPort by integrated Intel graphics (DP1-DP2) Same as AVA-5500, 4x DisplayPort by MXM GPU module: additional support for DisplayPort... - Page 18 Leading EDGE COMPUTING Model AVA-5500 AVA-5510 AVA-5520 USIM 2x micro-SIM card slots (accessible on the front panel) Buttons Power button, reset button Status LEDs 1x Diagnostic, 1x Storage,1x WDT, 3x User Defined Camera Interfaces 4x M12 Class 2 (7W) Internal I/O Interfaces 1x M.2 2280 SATA Slots 2x Full-size Mini PCIe slots...
- Page 19 AVA-5500 Model AVA-5500 AVA-5510 AVA-5520 CMOS Battery Model BR-2032 Protection Reverse charge protection Firmware/Software Support SEMA SEMA support with BMC Watch Dog Timer support Operating Systems Windows Windows 7 Professional, Windows 8, Windows 10 Linux Ubuntu 16.04 Environmental & Safety Convection cooled Class OT1: -25°C to 55°C with NVIDIA 0°C to 55°C with...
-
Page 20: Displayport Feature Support
Leading EDGE COMPUTING The MXM module must be installed at the factory. Please contact your local ADLINK representative for more information. When an MXM graphics module is installed, the default Primary NOTE: NOTE: Display BIOS setting (Auto) will send bootup display output to DP3-DP6 (MXM graphics). -
Page 21: Block Diagram
AVA-5500 2.3 Block Diagram Power conn. M12 S-coded Power +24/+36VDC or 4-pin Board +72/+110VDC (+/- 40%) input Main Board AFM Board DB9 x2 Intel® Core™ i7-6820EQ for CAN Intel® Core™ i7-7820EQ (optional) QM170 Chipset USB 3.0 Type A x4 SODIMM x2 GbE (RJ-45) Ethernet DDR4 2133 8GB... -
Page 22: Mechanical Dimensions
Leading EDGE COMPUTING 2.4 Mechanical Dimensions AVA-5500/5520 (units: mm) 225.1 88.8 Figure 2-2: AVA-5500/5520 Dimensions System Description... -
Page 23: Figure 2-3: Ava-5510 Dimensions
AVA-5500 AVA-5510 ( nits: mm) 225.1 105.4 Figure 2-3: AVA-5510 Dimensions System Description... -
Page 24: Mechanical Layout
Leading EDGE COMPUTING 2.5 Mechanical Layout Front View Figure 2-4: AVA-5500 Series Front Layout AVA-5510 shown) M12 A-code GbE M12 X-code GbE with PoE Class 2 RS232/422/485 USB 3.0 RJ-45 GbE DVI-I DisplayPort* Mic-in Line-out PS/2 Power On/Off button System Reset button M12 USB 2.0 (AVA-5510 only) -
Page 25: Figure 2-5: Ava-5500/5200 Rear I/O Layout
AVA-5500 Rear View Figure 2-5: AVA-5500/5200 Rear I/O Layout Figure 2-6: AVA-5510 Rear I/O Layout 2.5” SATA Drive Bays CFast Slot DC Input Ground Stud System Description... -
Page 26: Power Specifications
Leading EDGE COMPUTING 2.6 Power Specifications 2.6.1 Power Consumption The following table presents the AVA-5500 Series power con- sumption data at room temperature under the following test condi- tions. Intel® Core™ i7-6820EQ Memory: NVIDIA P1000 GPU: 8GB NVIDIA P3000/P5000 GPU: 32GB Storage: M.2 SATA 64GB... -
Page 27: System Power Features
AVA-5500 Input Power Loading Setup Current Voltage Consumption Stress: Windows typical mode, (Burnintest tool & 14.75A 177W GPU Heater) GPU: P5000 Stress: Windows MAX mode, 17.15A 205.8W (Intel TAT & GPU Heater) 12VDC S3 mode 450mA 5.4W S4 mode 400mA 4.8W S5 mode 380mA... -
Page 28: Mini Pcie Can Bus Module (Optional)
Leading EDGE COMPUTING Under Voltage Lockout (UVLO) The under voltage lockout feature will shut down the power if the input voltage is below 14V+/- 0.4V and automatically restart when the input voltage is above 16+/- 0.4V. 2.7 Mini PCIe CAN Bus Module (optional) An optional Mini PCIe Card CAN Bus Kit consisting of an Innodisk EMUC-B202 Mini PCIe CAN bus module and cable can be installed at the factory. -
Page 29: Getting Started
AVA-5500 Getting Started Follow the instructions in this chapter to install USIM cards; Wi-Fi, cellular and M.2 SATA modules; mounting brackets; CFast card; 2.5” SATA drives; ground cable; and DC power supply. MXM and CAN bus modules must be installed at the factory. Please contact your local ADLINK representative for more information. -
Page 30: Installing Wi-Fi Or Cellular Modules (Optional)
Leading EDGE COMPUTING 3.2 Installing Wi-Fi or Cellular Modules (optional) Follow the instructions below to install a Mini PCIe Wi-Fi or cellular module. 1. Insert the Mini PCIe LTE or Wi-Fi module into one of the slots as shown and secure it using two M2.5 screws. Mini PCIe modules antenna holes Slot 1... -
Page 31: Installing A M.2 2280 Sata Module (Optional)
AVA-5500 3.3 Installing a M.2 2280 SATA Module (optional) To install an M.2 2280 SATA module, insert the module into the slot and secure it with one M2.5 screw as shown. M.2 module M.2 modules may require an additional thermal solution when operated above 60 °C. -
Page 32: Installing Micro-Usim Cards (Optional)
Leading EDGE COMPUTING 3.4 Installing micro-USIM Cards (optional) The micro-USIM card slots are located at the left of the front panel. Open the USIM card slot cover by removing the 2 screws indi- cated below. Insert the USIM cards into the slots using the orienta- tions indicated on the front panel (SIM2 contacts facing down, SIM1 contacts facing up) with the beveled (cut) corner facing out- wards. -
Page 33: Mounting
AVA-5500 3.5 Mounting The AVA-5500 can be wall or surface mounted using the wall mount brackets and screws provided. If wall mounting, make sure the wall can support the weight of the device. Secure the brackets to the chassis using the 6 screws provided as shown. Getting Started... -
Page 34: Cfast Card Installation
Leading EDGE COMPUTING 3.6 CFast Card Installation To install or remove the CFast card, remove the screws securing the CFast slot cover and remove the cover. Insert the CFast card and secure the cover. CFast card slot cover Getting Started... -
Page 35: Sata Drive Installation
AVA-5500 3.7 SATA Drive Installation To install a 2.5” SATA drive, loosen the captive screw securing the drive bay cover and remove the drive bracket. Install the 2.5” SATA drive into the bracket and secure with four screws. Insert the drive bracket assembly into the drive bay and secure the cover with the captive screw. -
Page 36: Connections
Leading EDGE COMPUTING 3.8 Connections Connecting a Ground Cable Connect the ground cable before making any other connec- tions. When disassembling the system, always detach the ground cable last. CAUTION: Use a ground cable with a cross section of at least 0.823mm (18AWG) and an M5 size ring terminal. - Page 37 AVA-5500 Connecting the Power Supply Work on the computer system may only be carried out by personnel qualified for the specific task and who have the training and experience to identify risks and WARNING: avoid potential hazards. Make sure that a ground cable has been connected to the system before connecting an external power supply and switching on the system.
-
Page 38: Starting Up The System
Leading EDGE COMPUTING 3.9 Starting Up the System Upon startup, the system will auto-detect storage devices and boot from the operating system, if found. To change the boot device order, press <Del> or <Esc> to enter BIOS setup menu and change the Boot Option settings. -
Page 39: Interfaces
AVA-5500 Interfaces 4.1 Pin Definitions Please refer to Figure 2-4 AVA-5500 Series Front Layout on page 12 for connector locations. GbE M12 A-code Connectors Pin # Signal Name MDO0P MDO0N MDO1P MDO1N MDO3P MDO3N MDO2N MDO2P Table 4-1: GbE M12 A-code Pin Definition... -
Page 40: Table 4-3: Usb 3.0 Pin Definition
Leading EDGE COMPUTING USB 3.0 Connector Pin # Signal Name +5V_USB3 USB2_P0_DN USB2_P0_DP USB3_P0_RXN USB3_P0_RXP USB3_P0_TXN USB3_P0_TXP Table 4-3: USB 3.0 Pin Definition COM DB9 Connectors Pin 1 Pin 5 Pin 6 Pin 9 Pin # RS-232 RS-422 RS-485 Pin1 TXD- Pin2 TXD+... -
Page 41: Table 4-5: Rj-45 Gbe Pin Definitions
AVA-5500 RJ-45 GbE Connectors 10BASE-T/ Pin # 1000BASE-T 100BASE-TX LAN_TX0+ LAN_TX0- LAN_TX1+ — LAN_TX2+ — LAN_TX2- LAN_TX1- — LAN_TX3+ — LAN_TX3- Table 4-5: RJ-45 GbE Pin Definitions Speed Activity Speed LED Activity LED Status (Green/Amber) (Yellow) Network link is not established or system powered off Link 10 Mbps... -
Page 42: Table 4-7: Dvi-I Connector Pin Definition
Leading EDGE COMPUTING DVI-I Connector Pin # Signal Pin # Signal TMDS Data2- Hot Plug Detect TMDS Data2+ TMDS Data0- TMDSData0+ DDC Clock [SCL] DDC Data [SDA] Analog vertical sync TMDS Clock + TMDS Data1- TMDS Clock - TMDS Data1+ Analog Red Analog Green Analog Blue... -
Page 43: Table 4-8: Displayport Pin Definition
AVA-5500 DisplayPort Connectors Pin # Signal Pin # Signal CN_DP0_P Ground CN_DP0_N CN_DP1_P Ground CN_DP1_N CN_DP2_P Ground CN_DP2_N CN_DP3_P Ground CN_DP3_N CN_CAD-L CN_CEC CN_AUX_P Ground CN_AUX_N DDP_HPD Ground P3V3 Table 4-8: DisplayPort Pin Definition PS/2 Keyboard/Mouse Connector Pin # Signal Function KBDATA Keyboard Data... -
Page 44: Table 4-11: Usb 2.0 M12 Connector Pin Definition
Leading EDGE COMPUTING USB 2.0 M12 Connector (AVA-5510 only) Pin # Signal Data - Data + Table 4-11: USB 2.0 M12 Connector Pin Definition CAN Bus DB9 Connectors (optional) The location and pin definitions of Port 0 and Port 1 of the optional CAN Bus module are as shown below. -
Page 45: Table 4-13: Dio Db9 Connector Pin Definition
AVA-5500 DIO DB9 Connectors (optional) The location and pin definitions of the optional DIO connectors are as shown below. Pin # Port 0/1 Port 0 Port 1 DI_COM0/1 Pin 1 Pin 5 P_+VD0_EXT1 Pin 9 Pin 6 P-+3V3_Do_GND Table 4-13: DIO DB9 Connector Pin Definition Optical Isolated Input Channel Number of Channel 2 DI... -
Page 46: Table 4-14: Mini Pci Express Connector Pin Definition
Leading EDGE COMPUTING Mini PCIe Connector Signal Name Signal Name PCIE_WAKE# P_+3V3_MPCIE P_+1V5_S MPCIE0_CLKREQ# P_+3V3_UIM UIM_DATA REFCLK_MPCIE_N UIM_CLK REFCLK_MPCIE_P UIM_RST UIM_VPP PLTRST_MINIPCIE-L MPCIE_RXN P_+3V3_MPCIE MPCIE_RXP P_+1V5_S MPCIE_CLK MPCIE_TXN MPCIE_DAT MPCIE_TXP MPCIE_USB_N MPCIE_USB_P P_+3V3_MPCIE P_+3V3_MPCIE P_+1V5_S P_+3V3_MPCIE Table 4-14: Mini PCI Express Connector Pin Definition Interfaces... - Page 47 AVA-5500 M.2 Connector Signal Name Signal Name P_+3V3_NGFF P_+3V3_NGFF KEY-B NGFF_DEVSLP NGFF_SATA_RXP NGFF_SATA_RXN NGFF_SATA_TXN NGFF_SATA_TXP Interfaces...
-
Page 48: Table 4-15: M.2 Connector Pin Definition
Leading EDGE COMPUTING Signal Name Signal Name NGFF_SUSCLK P_+3V3_NGFF P_+3V3_NGFF P_+3V3_NGFF Table 4-15: M.2 Connector Pin Definition Interfaces... -
Page 49: Status Leds
AVA-5500 4.2 Status LEDs LED indicator Color Description When blinking, indicates the SATA drive is SATA Drive active. Indicates watchdog timer status. When watchdog timer starts, the LED flashes. Watchdog (WD) Amber When the timer is expired, the system will auto reboot. -
Page 50: Power Button
Leading EDGE COMPUTING 4.3 Power Button The power button is non-latched, with a blue LED indicator. Sys- tem is turned on when the button is depressed, and the power LED lights. If the system hangs, depressing the button for 5 sec- onds to turn off the system completely. -
Page 51: Bios Setup
AVA-5500 BIOS Setup 5.1 Introduction The following chapter describes basic navigation for the AMI EFI BIOS setup utility. 5.2 Entering BIOS Setup To enter the setup screen, follow these steps: 1. Power on the motherboard 2. Press the < Delete > key on your keyboard when you see the following text prompt: <... - Page 52 Leading EDGE COMPUTING Navigation The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot keys can be used at any time during the setup navigation process. There is a hot key legend located in the right frame on most setup screens.
- Page 53 AVA-5500 Hotkey Descriptions The < Enter > key allows you to display or change the setup Enter option listed for a particular setup item. The < Enter > key can also allow you to display the setup sub-screens. The < F1 > key allows you to display the General Help screen.
- Page 54 Leading EDGE COMPUTING The < F9 > key on your keyboard is the optimized defaults key. To set the optimized defaults settings of the BIOS, press the < F9 > key on your keyboard. It is located on the upper row of a standard 101 keyboard.
-
Page 55: Main Setup
AVA-5500 5.3 Main Setup The Main Menu provides read-only information about system and also allows to set system's date and time. 5.3.1 BIOS Information BIOS Item Options Description BIOS Vendor Display vendor name of system Info only BIOS. American Megatrends BIOS Version Display version of booting BIOS. -
Page 56: System Information
Leading EDGE COMPUTING 5.3.2 System Information BIOS Item Options Description Project Name Display the project name. Info only AVA-5500 CPU Board Version Info only Display the CPU board HW version. A1/A2/A3/… CPU Brand String Display what CPU is booting the Info only system. -
Page 57: Board Information
AVA-5500 5.3.4 Board Information BIOS Item Options Description Serial Number Display board’s serial number. Info only Manufacturing Date Info only Display manufacturing date. Last Repair Date Display Last Repair Date. Info only MAC ID Display onboard Ethernet MAC ID. Info only Total Runtime The returned value specifies the total Info only... -
Page 58: Advanced Menu
Leading EDGE COMPUTING 5.4 Advanced Menu This menu contains the settings for most of the user interfaces in the system. BIOS Item Options Description CPU Configuration For configuring CPU features/ Submenu functions. Graphic Configuration For setting graphic controller Submenu parameters. Power Management Submenu System Management... -
Page 59: Cpu Configuration
AVA-5500 5.4.1 CPU Configuration BIOS Item Options Description Active Processor Number of cores to enable in each Cores processor package Hyper-Threading Disable Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Enable Technology) and Disabled for other OS (OS not optimized for Hyper- Threading Technology). - Page 60 Leading EDGE COMPUTING BIOS Item Options Description ConfigTDP Turbo Info-only. Power Limit 1 Info-only. Power Limit 2 Info-only. Custom Settings Info-only. Nominal Config TDP Nominal Power Limit 1 45000 Power Limit 1 in milliwatts. Overclocking SKU: Value must be between Max and Min Power Limits (specified by PACKAGE_POWER_SKU_MSR).
-
Page 61: Graphics Configuration
AVA-5500 5.4.2 Graphics Configuration BIOS Item Options Description Primary Display Select which of IGFX/PEG/PCI Auto Graphics device should be Primary IGFX Display Or select SG for Switchable Gfx. Internal Graphics Keep IGFX enabled based on the Auto setup options. Disable Enable 5.4.3 Power Management... -
Page 62: System Management
Leading EDGE COMPUTING 5.4.4 System Management BIOS Item Options Description Version xxx Show the BIOS design of system Info only management. SEMA Firmware Show SEMA firmware version Read only installed on system. Build Date Show when SEMA firmware was Read only built. - Page 63 AVA-5500 BIOS Item Options Description Boot Counter If this item is shown, it means SEMA Info only supports “Boot Counter”. TVIA BMC If this item is shown, it means SEMA Info only supports “TVIA BMC”. Flags BIOS Item Options Description BMC Flags Show current BMC settings.
-
Page 64: Thermal Management
Leading EDGE COMPUTING 5.4.5 Thermal Management BIOS Item Options Description CPU Temperature Current Show current CPU temperature Read only gotten from sensor. Startup Show the CPU temperature at Read only system power up. Show the minimum CPU Read only temperature after system boot. Show the maximum CPU Read only temperature after system boot. -
Page 65: Csm Configuration
AVA-5500 5.4.7 CSM Configuration BIOS Item Options Description CSM Support This option controls if CSM will be Enabled launched. Disable CSM16 Module Info only Version Boot Option filter UEFI and Legacy This option controls what devices system can to boot. Legacy only UEFI only Option ROM... -
Page 66: Super Io Configuration
Leading EDGE COMPUTING 5.4.8 Super IO Configuration BIOS Item Options Description Serial Port 1 Submenu Configuration Serial Port 2 Submenu Configuration Serial Port 3 Submenu Configuration Serial Port 4 Submenu Configuration 5.4.9 Serial Port x Configuration BIOS Item Options Description Serial Port Disabled Enable or disable serial port... -
Page 67: Serial Console Redirection
AVA-5500 5.4.10 Serial Console Redirection BIOS Item Options Description COMx Console To enable or disable console Disabled Redirection redirection of COMx. Enabled COMx Console The settings specify how the host Submenu Redirection computer and the remote computer Settings (which the user is using) will exchange data. - Page 68 Leading EDGE COMPUTING BIOS Item Options Description Parity Configures if parity bit is generated None (transmit data) or checked. Even A parity bit can be sent with the data bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in the data bits is even.
-
Page 69: Miscellaneous
AVA-5500 COMx Legacy Console Redirection Settings BIOS Item Options Description Redirection COM Select a COM port to display COM1 Port redirection of Legacy OS and COM2 Legacy OPROM Messages COM3 COM4 Redirection Set console display resolution. 80x24 80x25 Redirection After The setting specifyies if BootLoader Always Enabled POST... - Page 70 Leading EDGE COMPUTING PEG Port Configuration BIOS Item Options Description Enable Root Port Disable Enable or Disable the root port Enable Auto Max Link Speed Configure PEG 0:1:0 Max Speed Auto Gen1 Gen2 Gen3 SATA and RTS Configuration BIOS Item Options Description SATA Controller(s)
-
Page 71: Network Stack Configuration
AVA-5500 BIOS Item Options Description SATA Device Type Identify the SATA port is connected Hard Disk Drive to Solid State Drive or Hard Disk Solid State Drive Drive. Topology Unknown Identify the SATA Topology if it is Default, ISATA, Flex, DirectConnect ISATA or M2. -
Page 72: Intelethernet Connection (2) I210-Lm
Leading EDGE COMPUTING 5.4.14 IntelEthernet Connection (2) I210-LM BIOS Item Options Description NIC Configuration For configuring link speed and wake Submenu function. Blink LEDs Identifies the physical network port Value Range by blinking the associated LED. NIC Configuration BIOS Item Options Description Link Speed... -
Page 73: Security Menu
AVA-5500 5.5 Security Menu This menu contains the settings for security in the system. BIOS Item Options Description Administrator Configure/Clear Administrator Enter to set Password Password. password When pressing enter, a menu will be popped up for creating new password. When password installed, press enter without inputting password, it will clear password. -
Page 74: Boot Menu
Leading EDGE COMPUTING 5.6 Boot Menu This menu contains the settings for bootable devices in the sys- tem. BIOS Item Options Description Setup Prompt Number of seconds to wait for setup Timeout activation key. 65535 (0xFFFF) means indefinite waiting. Bootup NumLock Select the keyboard NumLock state State after system boot. -
Page 75: Save & Exit Menu
AVA-5500 5.7 Save & Exit Menu BIOS Item Options Description Save Changes and Save changed settings and exit Enter Exit BIOS setup utility. Discard Changes Skip changed setting and exit BIOS Enter and Exit setup utility. Save Changes and Save all changed settings and let Enter Reset system do reset to boot system. - Page 76 Leading EDGE COMPUTING This page intentionally left blank. BIOS Setup...
-
Page 77: Important Safety Instructions
AVA-5500 Important Safety Instructions For user safety, please read and follow all instructions, WARNINGS, CAUTIONS, and NOTES marked in this manual and on the associated equipment before handling/operating the equipment. Read these safety instructions carefully. Keep this user’s manual for future reference. Read the specifications section of this manual for detailed information on the operating environment of this equipment. - Page 78 Leading EDGE COMPUTING A Lithium-type battery may be provided for backup power. Risk of explosion if battery is replaced with one of an incorrect type. Dispose of used batteries appropriately. WARNING: Never attempt to fix the equipment. Equipment should only be serviced by qualified personnel.
-
Page 79: Getting Service
San Jose, CA 95138, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-360-0222 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com...
