9. Set the following parameters specified by your service provider. If not, leave these values at the default
setting:
Field
Full Status Polling Cycles - the number of status inquiries between
n391
n392
Monitored Events Count - the number of status messages that are
n393
tracked to determine if more than n392 errors have been detected.
Link Integrity Verification Timer - Time to wait between sending each
t391
10. Set the PVC parameters.

Setting the Frame Relay PVC Parameters

1. Use the arrow keys to access the following PVC_Setup menu.
MI Path
Configuration->Connect->T1/Frame_Relay->PVC Setup
2. Press the → key to access the PVC parameters screen.
3. Set the Voice PVC Supported Service parameter for the EXTender link to RVP_over_Frame_Relay.
4. Set the DLCI (Data Link Connection Identifier) for this PVC (16 - 1007). This number is given to you by
your service provider. The DLCI field defaults to blank and is cleared automatically if you set the PVC
type to "Not In Use."
TM
EXTender 7000 Installation Guide
Table 4: LMI T1 Parameters
Definition
each full status report.
Error Threshold number
status inquiry message.
Figure 3-28: T1/PVC Setup Menu
Figure 3-29: PVC_1
Default
Value
6
3
4
10
Page 46
