that this setting be left at 100.
10. Press the ← key to accept the changes and go back to the Configuration menu.
11. Press the ↓ key to navigate to the Save parameter.
IP Parameters
An Internet Protocol (IP) address and associated routing parameters must be entered within the IP menu of
the EXTender for identification purposes within the LAN (Local Area Network).
Note: The IP address (as well as any required mask or router addresses) must be provided by the network
administrator.
Setting
Address
This is the IP address of the EXTender.
Subnet Mask
A number used to identify the IP subnetwork on the LAN.
Default Router
The address of a device used to reach IP hosts not on this IP subnetwork.
Telnet
This parameter must be Enabled to allow access to the Management Interface via a
Telnet session.
Web Server
This parameter must be Enabled to allow access to the Management Interface via a
web browser (Microsoft Internet Explorer 5.x or higher, or Netscape Communicator
4.7x or higher).
Setting the Network IP Addresses
1. Access the IP Address Menu using the following path:
MI Path
Configuration->IP->LAN->Address
TM
EXTender
7000 Installation Guide
Figure 3-21: RVP_Over_IP
The following IP settings are required:
The following IP settings are optional:
Description
Page 41
