Site Controller
Replacement

Removal

68P80801E30-A 5/1/2002
Perform Site Controller replacement as described in the following
paragraphs.
Remove the Site Controller from the Equipment Cabinet as follows:
Remove power from the Site Controller by setting the Power Supply
1.
ON/ OFF switch to OFF.
Set CTRL A and CTRL B breaker switches (as applicable) to OFF.
2.
Tag and disconnect the cabling from the Site Controller rear panel
3.
connectors.
Remove the four M6 TORX screws which secure the Site Controller
4.
front panel to the Equipment Cabinet mounting rails.
While supporting the Site Controller, remove the Site Controller
5.
from the Equipment Cabinet by sliding the Site Controller from front
of the cabinet.
