Chapter 6 System Testing

Loading the Base Radios

Loading the Base Radios
6-12
The Base Radio (BR) software must be downloaded to each legacy BR. The
software automatically transfers to each legacy BR connected to the site
controller.
This procedure refers to legacy BR only. Quad BR installation
Note:
software is resident on the Base Radio and does not need to be
downloaded from iSC. Quad BR must be switched to test mode, by
performing diagnostic reset (press reset button located on the BR
front panel and follow on screen instructions), in order to activate
BR installation software. Refer to System Testing section in Volume
1 (System Installation and Testing) of EBTS manual for more
information.
On the RF Cabinet breaker panel, set all BR breakers to OFF.
1.
Apply power to a single BR via the breaker panel on the RF Cabinet
2.
and the power switch on the BR Power Supply.
This begins the download of the application code from the Controller.
During software download, the service computer displays a message
similar to the following:
iSC>
downloading code to BR...
cabinet 1 position 3
................
................
................
................
................
Complete Downloading code to BR...
If an error occurs during the downloading process, reset the BR to
Note:
start downloading again.
