Result Display
In display area, you can set different judge methods of image detection result, including quantity,
angle, scale, etc.
In Judge Method, enable Judge by Quantity, Judge by Angle, Judge by Scale, Judge by Score,
Judge by Match Point X, Judge by Match Point Y, Judge by Center Point X, Judge by Center Point
Y, and enter corresponding range according to actual demands.
In Image Display, click
and fuzzing match point. Click
In OSD, enable Display Text to set text's color, front size, transparency, position X, and position Y.

7.4.2 Fixture Settings

Fixture is a tool for assisting the positioning and correcting the target motion deviation. The
position deviation reference can be set up according to the matching point and the matching
frame angle in the template matching result. And then the coordinate and rotation deviation of
ROI detection frame can be realized according to the relative deviation of feature matching result
and reference position.
Origin X
Link the matching point of template to the origin point of position deviation.
Origin Y
Link the matching point of template to the origin point of position deviation.
Reference Angle
Link the matching frame angle to the angle of position deviation.
Initialize Reference
Before creating a reference, you should click it.
Create Reference
Click Create Reference to create reference.
